Protection Circuit Module for 4Cells Li- Battery Pack

Brand Name	PCM-GIANT		Place of Origin	China
Model Number	ZFD10LRK-11A

Protection Circuit Module for 4Cells Li- Battery Pack Brand Name: PCM-GIANT Model Number: ZFD10LRK-11A Applications: Resistive load,4 cells Li-ion/Li-Polymer rechargeable battery pack Features and Benefits: High-precision voltage detection circuit Low static power consumption Low temperature co-efficient Strong anti-jamming capability Double current detection Specification: NO Test item(+25°C)with 3.7V Battery Criterion 2 Current Maximal continuous discharging current 20A 3 Over charge detection voltage Vco Single cell Over charge cutoff Voltage 4.25±0.025V 4 Over discharge detection voltage Vdo Single cell Over discharge cutoff Voltage 2.50±0.08V 5 Over current protection Over current detection voltage Viov 0.10±0.03V Over current protection current 33.0A Delay time 100ms 6 Current consumed in normal operation Current consumption 35.0uA 7 Sleeping mode power consumption Current consumption 0.1uA 8 Short circuit protection Detection delay time 0.4mS Release condition Cut load 9 Interior resistance Protection circuitry(working) 4.5mohm 11 Size L*W*H 51.8mm*39.2mm*7.8mm
