4 Channel Passive UTP Video Balun Transceiver CEE-TP06

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	CEE		Place of Origin	China
Model Number	CEE-TP06

Product Description

Delivery Time:1-1000pcs : 3 business days

CEE-TP06 is a high-definition AV signal passive UTP video balun transmitter which mainly used for security, education and other fields. It uses Cat5 or Cat5e as a transmission medium. It can real-time transmit 300 meters color or 600 meters black and white baseband video signal. its transmission distance will up to 1200m color signal or 1800m black and white signal if working with active receivers. it will save wiring costs, simplify your wiring works.

Feature
Real-time transmission of High-Definition video signals.
Transmission distance up to 300m working with passive transceivers, up to 1200m woring with HXVB-120R active receivers.
No power needed.
NTSC, PAL, SECAM video formats
Compact size and easy installation
Compatible with all qualified UTP cameras
ABS plastic shell fire, copper BNC connector, environmental terminal

Specification

Transmission?distance	0-300m
Signal?Type	Video(PAL, ?NTSC, ?SECAM?and?other?baseband?video?signal)
Connector	4?x?Coaxial?BNC(female), ?RJ45, ?twisted-pair?terminal
Frequency?response	DC?to?6MHz
CMRR	0?to?6MHz?60dB?(typical)
Impedance	Coax?(BNC?female)?75?Ohm;?UTP?(unshielded?twisted?pair)?100?ohms
Cable?Type	Cat5?or?Cat5e?unshielded?twisted?pair
Cable?Impedance	100?±?20?ohms
Distributed?capacitance	less?than?62pF/m
DC?loop?resistance	18?Ohm/100m
Operating?temperature	-20oC~70oC
Relative?Humidity	0~95%(non-condensing)
Storage?temperature	-40oC~150oC
Dimension	82mm?x?81mm?x?29mm
Net?Weight	80g

Use
??Security?and?Surveillance?
??Elevator?Surveillance?
??Video?Conferencing?
??Video?Distribution?
??P/T/Z?control?signals?
??PC?Multimedia
