2 PLF Series Double Tooth Roller Grading Stone Crusher
- 200 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | ZYM | Place of Origin | China | |
| Model Number | 2PLF |
Product Description
2 PLF Series Double Tooth Roller Grading Stone Crusher
Working Principle
2PLF series teeth-roller Stone crusher is driven by electromotor via reducer, two tooth-roller rotate inward
synchronously in opposite direction. After material dropping from the inlet to crushing chamber,firstly is classified by
the tooth-roller with tooth, those which is accepted would pass through the two rollers to the discharging trough,
and the massive materials would be crushed,cut, and then discharged in the discharging opening.
Structure and features
(1) Constant-filling fluid coupling
(2) Tooth-roller
Tooth-roller is the key component of crusher, spiral arrangement of teeth. The toothholders and principal axis are
assembled using the multiple dove-tail grooves, which enhance the shear strength.Small size materials are sieved
out by two tooth-roller which rotate inward synchronously in opposite direction, and the massive materials are
crushed by the broken tooth.Broken tooth is casted by adopting special formula which fuses multiple rare elements.
It is quenched after processing,make it higher strength as well as toughness,better abrasion resistance
and longer service life.
Where Choose the Model?
|
Model Specification |
2PLF-60/70 | 2PLF-60/120 | 2PLF-60/150 | 2PLF-60/200 |
| Inlet Size(mm) | <=400 | <=400 | <=400 | <=400 |
| Discharge Size(mm) | 50-150 | 50-150 | 50-150 | 50-150 |
| Capacity(t/h) | 80-240 | 200-600 | 250-700 | 300-800 |
| Single Driven Type Motor Power(kw) | 37-55 | 45-90 | 55-110 | 75-160 |
| Dual Driven Type Motor Power(kw) | 2*(15-37) | 2*(18.5-45) | 2*(37-55) | 2*(45-90) |
|
Model Specification |
2PLF-80/150 | 2PLF-S05/12 | 2PLF-S05/15 | 2PLF-S05/20 |
| Inlet Size(mm) | <=550 | <=550 | <=550 | <=550 |
| Discharge Size(mm) | 50-150 | 50-150 | 50-150 | 50-150 |
| Capacity(t/h) | 200-600 | 260-750 | 300-1000 | 400-1150 |
| Single Driven Type Motor Power(kw) | 132-160 | 160-200 | 185-250 | 250-280 |
| Dual Driven Type Motor Power(kw) | 2*(75-90) | 2*(90-132) | 2*(110-185) | 2*(132-220 |
|
Model Specification |
2PLF-120/150 | 2PLF-120/200 | 2PLF-120/250 | 2PLF-120/300 |
| Inlet Size(mm) | <=1200 | <=1200 | <=1200 | <=1200 |
| Discharge Size(mm) | <=300 | <=300 | <=300 | <=300 |
| Capacity(t/h) | <=1500 | <=2000 | <=2700 | <=3300 |
| Single Driven Type Motor Power(kw) | 315-355 | 355-450 | 450-560 | 560-630 |
| Dual Driven Type Motor Power(kw) | 2*(132-185) | 2*(160-220) | 2*(185-250) | 2*(200-315) |
|
Model Specification |
2PLF-140/150 | 2PLF-140/200 | 2PLF-140/250 | 2PLF-140/300 |
| Inlet Size(mm) | <=1500 | <=1500 | <=1500 | <=1500 |
| Discharge Size(mm) | <=300 | <=300 | <=300 | <=300 |
| Capacity(t/h) | 1300-2500 | 1700-3800 | 2200-4600 | 2700-5500 |
| Single Driven Type Motor Power(kw) | 315-355 | 355-450 | 400-560 | 450-630 |
| Dual Driven Type Motor Power(kw) | 2*(185-280) | 2*(200-315) | 2*(220-355) | 2*(250-400) |
