Roller Sorting Machine

Products model:HRT-1201


Range of application
This new roller sorting machine is mainly used for selecting size precision of the
steel balls automatically. The precision ≤0.001mm is very applicable to size precision selecting of difference diameter steel balls. During rough sorting period, it also can
be used to pick different balls, scrapped parts and surface defected balls out. Meanwhile, it is applicable to various sizes of hi-precision metal and electronic components.

Structural Features
This machine is designed by totally enclosed type, shapely and clean, good dustproof performance.  There are total 4 groups sorting rollers to operate, which being 4 times efficiency compare with traditional machine, but 1/4 labor cost only, equipped with a special classified collecting box and the corresponding sensor, also designed with moisture-proof device and HD industrial camera. Our latest patented roller designing improve precision sorting to ≦0.001mm. The auto-input material feeding system has been adopted to this new machine, which is capable for adjusting the feeding speed and sorting different size steel balls.

Main Technical Parameter
Ball size φ1.5mm--φ10mm
Precision ≤0.001mm
Roller effective classification length 460mm
Diameter of roller φ35mm
Velocity modulation range of the roller 0-260turn/minute
Vibration material input capacity 300-350kg

Motor total power 120W
Pulling force of vibration electromagnet ≥2.7KN
Source of electricity 220V/50Hz
Overall size (L × W × H) 1200x705x1560mm
Net weight 380kg
