2000Hz Large Scale Laser Subsurface Engraving Machine (LD-EG602C)

FOB Price

Negotiable / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Lead Laser		Place of Origin	China
Model Number	LD-EG-602C

Product Description

2000Hz Large Scale Laser Subsurface Engraving Machine (LD-EG602C)

Function:
Our self-developed large scale laser subsurface engraving machines LD-EG-602C are used to engrave all kinds of patterns into transparent material such as glass, crystals, etc., as a decoration. When the engraved pattern glow in the lamplight, the engraved products can be used as tag, caution light and decoration. It is highly apply in architectural decoration, fashion home decoration, advertisement, photo studio, religion decoration and personalize crystal gift, etc.

Advantage:
1. Our LD-EG-602C Rapid Scanner Laser Subsurface Engraving Machine adopts the advanced galvanometer scanner technology together with 2KHz diode-pumped YAG frequency doubling laser which is faster, the laser point is more thin and bright, the image also will be more elaborate and lively.
2. The key parts of the apparatus mainly come from Germany and the USA. It is more reasonable and steady for long-term production.
3. It has original technology, and the maximum engraving range is 1500mmX 1000mm X80mm.

Technique Specification Of LD-EG-602C:
LD-EG-602C Laser Sub-surface Engraving Machine: Parameter
Product main technical index
Laser Medium: Diode Pump + YAG
F-theta lens(mm): F: 100
Pump source: Diode
Diode Pump useful time: 8000-20000 Hours
Laser Wavelength: 532nm (Green Laser)
Highest Frequency of Laser Power Supply: 2000 Hz
Resolution (DPI): 300-500
Maximum Engraving Range: 1500mm× 1000mm× 1~80mm
Engraving Speed: 80, 000-120, 000 dots/min
Average Production: 1 m2 / 1 Hours (About 5, 000, 000 dots)
Working Way: 1scanner + X-Y-Z
Repeated location accuracy: 10 μ M
Power Supply: 220V or 110V± 10% 50Hz or 60Hz
Power consumption: 2KW
Laser Head Number: 1
Continuous Working Time: 12 hrs
Working Current of the Whole Machine: 15 A
Control System: Servo control system
Deadweight of Main Machine: 450 kg
Dimension of Main Machine: 1400mm× 2100mm× 1200mm
Technical index of circulating water cooler
Cooling Power: 300 W
Water Medium: Deionized water or pure water
Refrigerating medium: Diode-cooling
Water Supply Pressure: 0.05 Mpa
Consumed Power: 300 W
Weight: 25 kg
Dimension: 270mm× 400mm× 350mm
Best Environment:
Temperature: 15-30
Relative humidity: <75%
After service:
Training time: 5-7 days
Warranty: 1 year.
Maintenance: Lifelong.
