UT631 Digital AC Milli Volt Meters

Basic Functions?

Range?

Best Accuracy?

AC Voltage?

1KHz

200Hz~500KHz

10Hz~200Hz
500KHz~2MHz

4mV

(1.0%+15)

(1%+0.1mV)

(2%+0.1mV)

40mV

(0.5%+15)

(3.0%+20)

(5%+20)

400mV

(0.5%+15)

(3.0%+20)

(5%+20)

4V

(0.5%+15)

(3.0%+20)

(5%+20)

40V

(0.5%+15)

(3.0%+20)

(5%+20)

400V

(0.5%+15)

(3.0%+20)

(5%+20)

Special Functions

Frequency Response Range

10Hz~2MHz

Noise Voltage

≤18 Digits

Input Impedance

R^≥10MW, C^≤47pF

Auto/Manual Ranging

?Yes

Dual Channel

?Yes

Max. Display

?4040

Power

220V ± 10%, 50Hz ± 4%, 7VA

LCD Size

157 x 36mm

Working Environment

Temperature: 23 ± 5°C, Humidity: <60%
Atmospheric Pressure: 86kpa~106kpa

Product Colour

Red and Grey

Product Net Weight

3.3kg

Product Size

370 x 222 x 106mm

Standard Accessories

Test Lead x 2, Power Cord, English Manual

Standard Individual Packing

Gift Box

Standard Quantity Per Carton

4pcs

Standard Carton Measurement

690 x 455 x 320mm(0.10CBM Per Standard Carton)

Standard Carton Gross Weight

23kg
