Home > Products > New product > 3ton Crawler Crane Specially used in narrow space construction
3ton Crawler Crane Specially used in narrow space construction
- 0 Unit / Units per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | KB Crane | Place of Origin | China | |
| Model Number | KB3.0 |
Product Description
|
Mini Telescopic Crawler Crane Specially used in narrow space construction 1.3T Crawler Crane with Remote Controller 2.Electric Dive or oil engine Drive 3.Small Size ,after folding ,can put into 20’container 4.Widely used in narrow space 5.High cost performance, factory directly selling |
Mini crawler crane Technical data
|
Model |
KB3.0 |
|
|
Specification |
3.0T×1.3m |
|
|
Max operation radius |
8.3m |
|
|
Max Raising height |
9.2m |
|
|
Winding |
Hook up speed |
2.5m/min |
|
The diameter and length of wire rope |
8mm×50m |
|
|
Telescopic |
Jib form |
5 parts (Full-automatic) |
|
Jib Length |
9 m |
|
|
Up and downs |
Jib angle |
0-75° |
|
Rotary |
Rotation angle |
360-degree continuous rotation |
|
Outrigger |
The form of outrigger |
First part automatic regulation,Second part manual regulation |
|
Maximum extend range |
4.3m×5.4m |
|
|
Walking device |
Walking style |
Mechanical(3 drive 1 revert) |
|
Walking speed |
1.4Km/h |
|
|
Crawler |
synthetic rubber |
|
|
Grade ability |
20° |
|
|
Ground pressure |
37Kpa |
|
|
Hydraulic oil tank volume |
26L |
|
|
Dimension(L.W.H) |
2850x760x1450(mm) |
|
|
Machine Weight |
1800Kg |
|
|
Gasoline Engine |
Model |
GX390(HONDA) |
|
Engine maximum output power |
13HP |
|
|
Ignition system |
Transistor ignition magnets (Non contacting) |
|
