44 key dimmer remote led controller for led strip

24/44 Key remote RGB led controller

Product Description
44key Dimmer remote LED  Controller/led dimmer control, rgb led controller, dmx led controller

1.Operating temperature: -20-60 °C
2.Power supply: optional DC6V, DC12V, DC24V (order specify required voltage)
3.Dimension: L105 × W75 × H29mm
4.Output: 3 CMOS open-drain output
5.With speed and brightness adjustment function
6.Color selection with the specified function, a control lock function
7.Connection: Optional Total Yang, common cathode
8.Static power consumption: <1W output current: <2A (per loop)
9.Output power: 5V: <30W, 12V: <72W, 24V: <144W
10. 16-color Light changes
11. 4 light styles, FLASH, STROBE, FADE and SMOOTH
12. Tune the LED light brightness
13.ON/OFF control
14. A remote control can handle MORE THAN ONE RGB Lamp
15. Input Voltage: DC5V,12V,18V,24V.

Application;

    LED intelligent contrioller is dedicated to adjust the brightness of LED lights, which adopted the most advanced PWM (Pulse-Width Modulation) digital brightness-adjusting technology at present, users can either operate manually or use the IR wireless remote controller to control the brightness in the distance, they are suitable for commercial and household 86-style socket installation, the socket can be installed outside or inside the wall. LED intelligent dimmer can meet different brightness requirements at different time, and can extend life tenure of LED, suitable for adjusting the brightness of both low-power and hi-power LED illumination lights, energy-saving
