HSIM-2430-W 24'' HDSDI Broadcast Monitor

????????????????????????????????????? Product Brief Introduction

High Brightness LCD Pannel

Auto Detect Color Format

3D Video Decoder

Motion-adaptive Interlace

10 Bit Signal Process

SDI Audio Embedded and Audio Display (VU+PPM)

Dual-Picture/Real-Time Display (PIP/PBP Function)

SWAP Function

Color Temperature Selection

Image Size Settings

Mark Settings

Support 3G-SDI Input(Optional)

Part Zoom in (Complementary Focus)

Vector

Luminance Distribution Histogram

TC Code Display

H/V Delay

3-Color Tally Indicator

?????????????????????????????????? LCD Monitor Specifications

Model Name

HSIM-2430W

Display Size

24〞

Resolution

1920×1200

Aspect Ratio

16﹕10

Video input/output

1×BNC

Y/C input/output

2×BNC

Component（YPbPr/YCbCr/RGB) input/output

3×BNC（Support 1080p）

HDMI/DVI/VGA

HDMI/DVI/VGA Input Optional

2 SD/HD-SDI Input/1 Output

SD/HD-SDI Auto-Detected

SDI Audio Embedded

8 Audio Channel Embedded/Optional 2 Channel Output

Audio Display(VU+PPM)

Display Volume Unit Meter & Peak Table

Analog Audio Input

3.5mm Headset Switch Cable

Audio Headset Output

3.5mm Headset Jack

Speaker

2.5W×2

Remoted Control

RS-232

Color System

PAL/NTSC/SECAM （Auto-Detected）

Two Pictures (PIP/PBP)

PIP Picture's Size/Position and windows can be sellected; all parameters can be adjusted independence.

Two Pictures Swap

Two Pictures in rapid Swap

Color Temperature
