C Section Steel Forming Machine

1. the rolling product standard(mm)  80*300*L

2. rolling speed  0-12m/min

3. rolling groups  17 groups

4.rolling material  using high quality GCr15 forged steel to whole quench numerical control process.(HRC58-62°)

5. The material principal axis   using high quality 45 steel to finish machining

6.Main motor power  15KW

7. hydraulic station cutting  11KW

8.punching cutting system

      1). the classify of punching   single row hole and double row hole

       2) the material of mould   Cr 12

      3)the hardness of heat treatment   HRC60-62°

9.Kind of drive   Chain wheel drive

10.electric control system   the whole machine use industry computer PLC to control.

11. the length of main machine   12m*2.5m*1m

12. the total weight of main machine   about 11 Tons

nfiguration accessory  emptying device …….a set
                                        Leveling device………a set
                                        Punching hole and cutting system…a set
                                        Hydraulic station ……… a set.
                                        Computer control system…….a set
                                        Retainer control system ….. a set

14. Other important parts of equipment ,standard parts,components are used in the well-known enterprises accessories.
