Sell PA Mixer Amplifier with Speaker Selector

Model No.:TI-60, TI-120, TI-240, TI-350
Product Origin:China
Brand Name:ITC Audio
Price Terms:FOB Guangzhou / Shenzhen / Hong Kong
Payment Terms:T/T
Certification:CCC, ISO9001, CE, RoHS
Description:Mixer amplifier with speaker selector: TI-60/TI-120/TI-240/TI-350 Public address mixer amplifier with built-in 5 zones speaker selector can provide a compact solution to a versatile PA system) With the built-in speaker selector, it is easy to configure a small to mid-size sound system. Priority muting is achieved via MIC 1 and EMC 1 for overriding music for paging and emergency alarms) 4 ohms, 70V and 100V speaker outputs are provided, extensive protection from short-circuit, clipping and over-temperature. Features: 1) Three MICs inputs 2) Two AUX inputs 3) Two EMC priority inputs 4) EMC 1 has priority over all inputs except MIC 1 5) Individual gain control for MIC and AUX 6) Bass and treble tone controls 7) 5 zones speaker selector Specifications: 1) Rated power output: TI-60: 60W, TI-120: 120W, TI-240: 240W, TI-350: 350W 2) Speaker outputs: 4Ω, 70V or 100V 3) Input: MIC 1-3: 2mV/600 ohms, unbalanced a) AUX1-2: 150mV/15kΩ, unbalanced b) EMC1-2: 150mV/15kΩ, unbalanced 4) Outputs: 600Ω, 1V 5) Frequency response: 40Hz-18kHz 6) S/N ratio: MIC 1-3: 66dB, AUX1-2: 80dB 7) THD: less than 0.1% at 1kHz, 1/3 rated power 8) Crosstalk: MIC: 80dB, AUX: 85dB 9) Muting function: MIC 1 overrides other input signals with 0-30dB attenuation. EMC 1 overrides all inputs except MIC 1 10) Controls: Individual gain controls, power switch. Bass: 10dB at 100Hz. Treble: 10dB at 100kHz 11) Indicators: power LED, LED level meter, protect and temp 12) Protection: AC fuse, short-circuit and high temperature 13) Power requirements: 100-120V Ac or 220-240V AC, 50-60Hz, 24V DC (optional) 14) Dimensions: 484 x 435 x 132mm 15) N.W.: TI-60: 14kg, TI-120: 15kg, TI-240: 17kg, TI-350: 18kg 16) Finish: panel: aluminum plate, black or gold (optional), case: steel plate, black
