Sell RG59 Dual Standard Cable

Place of Origin	China

Model No.:RG59
Product Origin:China
Brand Name:
Price Terms:FOB, CIF, CFR
Payment Terms:
Certification:
Description:Construction 1) Center conductor: 20AWG (0.81mm) solid copper/copper clad steel 2) Dielectric: 3.66mm foam PE 3) Shield: bonded aluminum foil 4) Braid coverage: 60% x 16 x 4 x 0.16mm aluminum-magnesium 5) Messenger: 1.15+0.05mm CCS (1.30 steel) 6) Jacket: 6.10mm PVC 7) Jelly/APD as per customers' special requirement Characteristics: 1) Impedance: 75+3 ohms 2) Capacitance: 54+3pF/m 3) Velocity of Propagation: 85% 4) Return loss: min. 20dB (5-2,300MHz) 5) Attenuation [@68o F. (20o C.)] Frequency (MHz) max. (dB/100 ft.): 1) 5 0.86 400 5.10 2) 55 2.05 450 5.40 3) 83 2.45 500 5.70 4) 187 3.60 550 5.95 5) 211 3.80 600 6.20 6) 250 4.10 750 6.97 7) 300 4.45 865 7.52 8) 350 4.80 1000 8.12 UL: CMX, CM, CATV, CL2, CMR Custom orders are accepted Inner packing: 100m/roll 100m/plastic (paper) roll 305m/wooden drum 1,000'/wooden drum Outer packing: Carton, pullout box, wooden drum
