Sell SGQ Series Web-Fed Glazing Machine

Model No.:3520181616
Product Origin:China
Brand Name:Zhenggang
Price Terms:
Payment Terms:
Certification:ISO9001
Description:This machine is a special equipment coating on roll paper and plastic film rolls. It is composed of feeding system, glazing coating part, drying box, winding delivery, and configured with the functions of correction, tension control, frequency-conversion speed-regulating, pneumatic roll-lifting. Automatic photoelectric correction mechanism, magnetic tension automatic control device, pneumatic roll lifting part, UV curing box and IR dryer are installed for your option. Detailed specifications are subject to be made according to your requirements and the data is only for your reference. Technical parameters: 1) Model: SGQ-1000, SGQ-1300, SGQ-1600 2) Width: 100mm, 1,300mm, 1,600mm 3) Diameter of roll: 1,000mm 4) Working speed: 0 - 35m/min 5) Thickness: 0.03 - 2mm 6) UV power: 2 x 8kW 7) IR power: 12 x 1kW, 12 x 1.5kW, 12 x 12kW 8) Total power: 35kW, 45kW, 60kW 9) Weight: 4MT, 4.8MT, 5.8MT 10) Dimensions: 9,970 x 2,300 x 2,100mm, 9,970 x 2,500 x 2,100mm, 9,970 x 2,800 x 2,100mm
