PP Pleated Membrane Filter Cartridge 2016
- Tianjin
- T/T
You May Like
Product Details
| Brand Name | Yitong | Place of Origin | China |
Product Description
Place of Origin:China
PP Pleated membrane filter cartridge
Product Description
YTPP Series Polypropylene(PP) pleated filter cartridge is made of the high accuracy PP membrane, with widely chemical compatibility, extremely low dissolved matter, and can be used in various filter situation.
Performance features
The entire PP structure, effectively avoid dissolved matter.
With widely chemical compatibility, it is suitable for most acid, alkali and solvent filter requirements.
Multi-layer filter structure, high pollutant holding capacity, long durability.
The high accuracy PP membrane makes sure filter effectiveness.
Technical parameter
| Filter cartridge structure | Filter area | 0.65㎡ |
| Filter membrane | PP | |
| Guide layer | PP | |
| Inner support、cap、shell | PP | |
| Seal ring material | Silicone rubber、Viton、EPDM、PTFE | |
| Working situation | working temperature | ≤80℃ |
| Maximum working pressure difference （Forward direction） | 0.4Mpa/23℃ | |
| 0.21Mpa/80℃ |
Product type guide
| YTPP | Filteration Accuracy | Length | Connection Type | Seal ring material |
| 0010=0.1μm | 05=5" | 2=222 | S=Silicone rubber | |
| 0022=0.22μm | 10=10" | 6=226 | E=EPDM | |
| 0045=0.45μm | 20=20" | 15=215 | P=PTFE | |
| 0100=1μm | 30=30" | DOE/SOE=Flat head with gasket | V=Viton | |
 | 40=40" |
Minimum Order :500pcs
Supply Ability :20000pcs/month
