Stainless Steel SS316L Sanitary Filterswith Clamp End,304/316/304L/316L
- Shanghai/Ningbo
- T/T L/C Other
- 15 days
You May Like
-
Triplet Sanitary Ball Valve
-
Low Cost and High Quality Sanitary Stainless Sanitary Manhole Cover Series
-
Sanitary Stainless Steel Check Valve
-
Popular High Quality Cheap Stainless Steel Cartridge Filter Housing
-
High Precision and Low Price Sanitary Stainless Steel Ball Valves
-
SS304 SS316 JZ5 Sanitary Stainless Steel Thread Angle Seat Valve
Product Details
| Brand Name | AVM | Place of Origin | China | |
| Model Number | SMS , DIN , 3A ,ISO , RJT ,ID | Material | Stainless Steel | |
| Application | Commercial Kitchen | Structure | Pressure Reducing | |
| Standard or Nonstandard | Standard | Pressure | Medium Pressure | |
| Power | Pneumatic | Port Size | Standard | |
| Media | Acid | Temperature of Media | Normal Temperature |
Product Description
Material: SS304/SS316L stainless steel.
Size: 1"- 4", din standard is optional. DN25-DN100.
Finish: Polished inside and outside.
Ends: Welded, Male thread, Triclamp.
Inner Mesh: any mesh is OK.
Tri Clamp side inlet strainers and inline strainers come with 3 grades of fine mesh (50 mesh, 100 mesh, 150 mesh), the higher the number, the less porous the mesh. The side inlet strainer is the preferred choice simply because one does not have to disconnect the whole assembly to replace or clean the screen mesh. The inline strainer performs the same function, but mounts more similar to a spool with both ends clamped into a fitting. It is recommended that a strainer be placed after a pump, but prior to a plate chiller to reduce the debris entering the chiller, and ultimately the fermentation tank. The mesh is designed to be porous enough to permit trub and hop through for a healthy fermentation, but not so fine as to easily clog.
Best stainless steel wing nut anchor bolt for construction fastener bags+cartons+pallets according to customer ' s requirement,Best stainless steel wing nut anchor bolt for construction fastener bags+cartons+pallets according to customer ' s requirement,
A: We are factory.
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
