mdf board cutting machine with CE
- 300 Set / Sets per Month
- qingdao
- T/T Credit Card
You May Like
-
large capacity internal memory CNC JQ 1290 Laser machine
-
Non metal CNC JQ 1610 Laser Machine with single or double head
-
High quality CNC CO2 JQ 1610 Laser Machine with single or double head price
-
Good price nozzle of laser cutting machine in nashik
-
best selling metal and non-metal mixed laser cutting machine with cheap price
-
maquina laser co2
Product Details
| Condition | New | Laser Type | CO2 | |
| Applicable Material | Acrylic, MDF, Plywood, Wood | Cutting Thickness | 30-35mm | |
| Cutting Area | 1300*2500mm | Cutting Speed | 0-40000mm/min (0-1575 inch/min) | |
| CNC or Not | Yes | Cooling Mode | Water Cooling | |
| Control Software | Leetro conol system | Graphic Format Supported | AI, BMP, DST, DXF, PLT | |
| Place of Origin | Shandong, China | Brand Name | Jinqiang | |
| Model Number | JQ1325 | Certification | CE, Other, CE, FDA | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Standard export plywood case.
Product Description
mdf board cutting machine with CE
1. Features of JQ1325 cutting CO2 laser machine
a.The up to date software provides the output of original pictures, compatible with the graph formats such as CAD, CorelDraw, Photoshop, Tajima software, meet the practical design requirements of the end users. The advanced colour control supports various colours and sequence of the cutting, it can realize complete or partially output of the files.
b.USB data interface, use MSF can deposit multi-files at one time, can work offline and convenient for mass production.
- DSP controlling system, rich functions, can engrave and cut on various materials like acrylic, wood, fabric, leather, MDF and other non-metal materials
- Owns functions of restoring from power off, continuation on break point.
- USB(off-lie) control system
- Compatible with CORELDRAW, PHOTOSHOP, AUTOCAD, TAJIMA, etc
- 0.01mm locating precision
- Noise free and dust free
- Imported singapore mirrors and lens
- Imported Taiwan rails, more stable and high precision
- Leetro MPC6535 control card combined with lasercut 5.3 software
2.Technical Performance Of JQ1325 cutting CO2 laser machine
Machine Model | JQ1325 CO2 laser machine for cutting acrylic |
Working Size | 1300mm*2500mm 51in*98in (L*W) |
Laser Power | 100W/150W/180W |
Laser Type | CO2 sealed high quality, water-cooling |
Driving System | Stepper motor |
Cutting Speed | 0-40000mm/min (0-1575 inch/min) |
Engraving Speed | 0-70000Mm/min (0-2756 inch/min) |
Resetting Position Accuracy | ≤±0.01 |
Power Supply | 220V/50Hz, 110V/60Hz, |
Operating Temperature | 0-45°C |
Operating Humidity | 5-95% |
Min. Shaping Character | English 1.0*1.0mm |
Operating System | PCI OR USB (DSP 6535) |
Graphic Format Supported | BMP, PLT, AI, DST, DXF |
Software Supported | Coreldraw, Photoshop, AutoCAD, Tajima |
Machine Dimension | 3350*2150*1250mm 131*84*49in |
Packing Dimension | 3450*2250*1350mm 134*87*52inch |
Net Weight | 1100kgs |
3.Applicabe material
Applicable Cutting Material (60W-180W Laser tube):
Acrylic/Perspex (1-30mm), MDF (1-18mm), Wood (1-30mm),
Cloth, Fabric, Dual-color board, Rubber, Leather, Paper
4.Guarantee and after-sale service
TWO year guarantee for whole machine except of laser tube and lens
24 hours technical support by e-mail, calling or door-to-door service
English software, user manual and detailed Videos CD
As a professional manufacturer we can supply different model according
to your different materials. So you also can tell me
1. What materials do you need to process? non metal material?
2. What is the size and thickness of each materials you want to cut?
3. What is your business scope? Are you an end user or distributor?
We will be very happy to help you in any way we can.
All these products are designed and developed by ourselves. We assure that we can provide goods with competitive price, high quality and best service. Looking forward to building a good relation in the future.
skype: jqlaser31
Phone:+86-1555 000 2101
FAQ
1.Q: Are you a factory or trading company?
A:We are a manufacturer with export license.
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Jinan City, Shandong Province, China, about 1 hours from Beijing, 2 hours from Shanghai and 2.5 hours from Guangzhou .All our clients, from home or abroad, are warmly welcome to visit us!
3.Q: Can you do OEM?
A: Yes, we can do OEM products. It's no problem.
4.Q:How can I get some samples?
A:1,We are honored to offer you samples. New clients are expected to pay for the courier cost, the samples are free for you, this charge will be deducted from the payment for formal order.
2,Regarding the courier cost: you can arrange a RPI (remote pick-up) service upon Fedex, UPS, DHL, TNT, etc. to have the samples collected; or inform us your DHL collection account. Then you can pay the freight direct to your local carrier company.
5.Q:How does your factory do regarding quality control?
A:"Quality is priority? JQ people always attach great importance to quality controlling from the very beginning to the very end:
1).All raw material we used are environmental-friendly;
2).Skillful workers care every details in handling the producing and packing processes;
3).Quality Control Department specially responsible for quality checking in each process.
If you are interest in our products or our services, please contact us, you will get the best reliable products in reasonable prices.
About us - Jinan JinQiang Laser CNC Equipment CO., LTD
*Workshop & Showroom
Workshop is the product of intense laser manufacturing center gold, bear manufacturing various types of laser equipment. Factory workshop area of 5075 square meters, the plant’s existing staff of 46 people, including management staff4, the worshop has three steps, the 10 team composition, with annual production of non-metallic series 4030, 6040, 9060, 1290, 1390, 1490,; cutting 1325, 1525, 1530, 1610, 1630; metal series 1325-YAG, 1325-fiber, 1530-fiber and other conventional and non-standard laser annual output of 3,000 sets of CNC equipment manufacturing capacity.
The 22st ShanghaiInt’lAd & Sign Technology & Eqipment Exhibition
2014 China International Industry Fair
The 23st ShanghaiInt’lAd & Sign Technology & Eqipment Exhibition
Company Profile
Jinan JinQiang Laser CNC Equipment Co.,Ltd is located in Jinan High & New Technology Industrial Development Zone. We are committed ourselves to developing, producing and selling laser equipment. Our company supplies JQ series of laser engraving and laser cutting equipment, laser engravers and laser cutters. They are used in many fields. With high quality products and top after-sales service, we have won trust and support of customers from all over the world. Our company is guided by the market-oriented concept as well as masterful technique, and regards "good service and customers' benefits" our rules. With technical development, and many years of research, our products are improved day by day. Our philosophy is "Golden Quality, The Best Technique and Good Faith". We are trying to be a well-known company at home and abroad with the perfect and considerate after-sales service system. We welcome customers from all over the world to cooperate with us. Please feel free to contact us for further information. Selecting JQ laser the world will become yours !
