SUDA YAG LASER MACHINE CUTTING METAL Hot Sale in 2014

Model  features

1.Machine structure  is welded body, heat treatment of the whole machine body, the stability and precision guaranteed.

2.Adopt 750W high power , quartz material aspheric lens  and double focusing lens, applied to both thick and thin material cutting

3.Height sensing cutting head adopt high accuracy imported servo system, with testing frequency as much as 20kHz/s

4.Adopt Japan YASKAWA  servo motor, THK square linear rail &high precision griding rolling boll screw, long life time.

5.Configured with professional industrial chiller, owning function of both refrigeration and heating. Can realize the effect of automatic frequency conversation with different season and environment

6.Adopt professional controlling system can design any kinds of graphic images and with oil lubricating system, easy to maintain.

Application

Mainly for metal material cutting, metal plate,metal tube like stainless steel, carbon steel, alloy steel, spring steel, aluminium alloy, copper plate, rare metals, wide applied for kitchenware, any hardware, metal plate structure,electrical cabinet,meter instrument,metal work presents,advertising signs,lamp decoration hardware,saws,spring piece,

aerospace,weapons,automobile parts,glasses,mechanical parts industry etc.

Technical data

Model type	TY1325	TY1530	TY1640
Laser media	Nd:YAG	Nd:YAG	Nd:YAG
Max. Power	600-750W	600-750W	600-750W
Wave length	1064NM	1064NM	1064NM
Max.speed	15-20m/min	15-20m/min	15-20m/min
Min.route width	0.15mm	0.15mm	0.15mm
Reposition accuracy	0.05mm	0.05mm	0.05mm
Pulse frequency	1-500Hz	1-500Hz	1-500Hz
Pulse width	0.1-20ms	0.1-20ms	0.1-20ms
Cutting width	1300*2500	1500*3000	1600*4000
Cutting thickness	less than 10mm	less than 10mm	less than10mm
Controller	Professional software control	Professional software control	Professional software control
Aiming positioning	Red  dot	Red  dot	Red  dot
Consume power	less than 20KW	less than 20KW	less than 20KW
Voltage requirement	380V/50Hz/60Hz /60A	380V/50Hz/60Hz /60A	380V/50Hz/60Hz /60A
Cooling way	Water cooling	Water cooling	Water cooling









Our Services



Our Services

  online:

one to one communication platform: Alibaba, skype, emails, MSN

if you have any problems, please contact with us

offline:

the machine has instruction in English , video

professional technician to train

we can arrange technician to your company to train

the parts of the machine if broken in the warranty, you can send to our company , but the fright should for your account.
