SINOTRUK Tipper Truck HOWO Tipper ZZ3317N2867W 8X4

Driving type

8x4

Body Dimension (LxWxH) (mm)

7300x2300x1000

Wheelbase (mm)

1800+3500+1350

Gross weight (kg)

31000

Cab

HW76 one berth with air conditioner

Left hand drive

VOSS Brake interface
VDO Instrument and Electric control
Behr Intercooler and water tank

Engine

SINOTRUCK brand WD615.96, High pressure common rail engine, 4-strokes, 6-cylinder, in-line direct injection type, dry cylinder line.

Turbo-charged

380PS

Euro 2 emission

Heavy Duty Battery, 24volts

Displacement: 9.726L

Ratio: 17:1

Transmission

HW19710 SINOTRUCK 10 speeds, 2 reverses

Maximum torque (N.m)/(r/min)

1900/1200~1500

Net weight of engine (kg)

850

clutch

strengthened Φ430  pull spring  clutch made by SINOTRUCK

Front axle

HF79 road use HOWO new 9 tonnage front axle, with disc brakes

Steering

ZF8098 (German)

Driving axle

AC16 casting steel axle, wheel reduction with differential lock

Rated payload: 16T,

Ratio: 5.45

Option: 4.47

Suspension

Steel plate spring suspension system

Tires

12.00-20 bias tires

Numbers of tires: 12+1 (spare tire)

Fuel tank (L)

400

Contact person: Lina Li

Tel:86- 152 6419 8219

1, Howo tippers: Howo 4x2 tipper; Howo 6x4 tipper; Howo 8x4tipper.

2, Howo concrete mixers: Howo 6x4 mixer; Howo 8x4 mixer. including 7m3,8m3,9m3,10m3,11m3 and 12m3,

3,Howo tracotrs: Howo 4x2 tractor; Howo 6x4 tractor

Engine power for the above heavy duty trucks are 266HP, 290HP, 336HP,371HPand 420HP.
