lab equipment/ Sigma extrusion machine Kneader

NO

ITEM

SPECIFICATION

1

Capacity

2L kneader

2

Electric power

Based on your factory electric

3

Material

All are stainless steel material

4

Motor power

0.75ith ZSY type reducer

5

Jacket

Heating jacket

6.

Lid of chamber

Stainless steel 304

7

Balde design

Blade in Z shape and clearence for cleaning

8.

Blade speed

Quicker 33,rpm lower 23,rpm

9.

Clearance of two blade

5mm

10

Support

Bench mountable

11

Discharge

Manual tilt discharge

12

Shaft seal

PTFE

13

Control cabinet

It will be Attached with the machine , with stop/start button an emergency stop button , also with digital temperature indicator

14

Delivery time

30days after received the deposite

15

Warranty

One year onece shipped to you

NO

ITEM

SPECIFICATION

1

Capacity

50L sigma mixer

2

Chamber

Stainless steel with the blade

3

Material

Body carbon steel and chamber SS 304

4

Motor power

11KW with ZSY reduction box

5

Jacket

Jacket for heating

6.

Heating power

4KW

6.

Lid of chamber

Silicon rubber sealed   ,and an valve with clips can be open and closed with sight glass

7

Balde design

Blade in Z shape and clearence for cleaning

8.

Blade speed

Quicker 45, lower 23. can be adjusted

9.

Clearance of blade

5mm

10

Vaccum

Needed insde ,general degree -0.094Mpa

11

Discharge

Screw extruder discharge   with extruder 7.5KW power

12

Vaccum pump

1.1KW power ,cycling by oil

13

Control cabinet

Attached with the machine , with stop/start button an emergency stop button , also with digital temperature indicator

14

Delivery time

35days after received the deposite

15

Warranty

One year onece shipped to you

16

Document attached

Operating and maintain manuals in english version,
