2014 Good China Raymond Mill Price for Powder Making
Negotiable
/ Set
1 Set(Min. Order)
- Qingdao Shanghai Tianjin etc.
- T/T Credit Card
You May Like
-
2014 Professional Mobile Crusher Station for Mining
-
Powerful Mobile Crushing System 180-200tph
-
China Strong Portable Jaw Crusher for River Stone Quarry
-
2014 Good Pricing Pebble Separator for Southeast Asia
-
2014 Brand New Small Gravel Rock Crusher PF1007 for Aggregte Plant
-
Big Limestone Jaw Crusher 600x900
Product Details
| Condition | New | Type | Raymond Mill | |
| Motor Type | AC Motor | Power(W) | 15kw for main machine | |
| Capacity(t/h) | 0.6-1.8 | Place of Origin | Henan, China | |
| Brand Name | UNIQUE | Model Number | 3R2115 | |
| Dimension(L*W*H) | 4500x2800x5800mm | Certification | ISO | |
| Warranty | more than one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Mill for Very Fine PowderVertical grinding
wide application for many kinds ore
low maintenance
smooth drive, reliable work
Based on sound quality products and good sales service, Unique company supplies Raymond mill which is suitable for grinding barite, calcite, potash feldspar, talcum, marble, limestone, ceramics, etc.
Raymond mill is a calssic type mill, which can be used to grind non-flammable and non-explosive materials in the fields of building materials, mining, metallurgy and chemical industry with raw material hardness less than 7.3 in Moh’s scale and humidity less than 6%.
Features
Three-dimensional structure
Land-saving
The screen-passing rate can reach to 99%
The transmission is steady and reliable
The transmission device of mainframe adopts airtight gear case and zonal wheel
Centralized control for the electric system, convenient to operate.
Model with spec
| Model | No. of Roller (Pcs) | Roller Diameter ×Height (mm) | Ring Inn Diameter ×Height (mm) | Max. Feeding Size (mm) | Fineness of finished product (mm) | Mainframe Power (KW) | Overall Dimension (L×W×H) (MM) | ||
| 0.125 | 0.075 | 0.044 | |||||||
| Capacity(t/h) | |||||||||
| 3R2115 | 3 | 210×150 | 630×150 | <15 | 1.2-1.8 | 0.6-1.2 | 0.6-1.0 | 15 | 4500×2800×5800 |
| 3R2615 | 3 | 260×150 | 780×150 | 15-20 | 1.8-2.5 | 1.2-1.8 | 0.8-1.2 | 18.5 | 5650×3305×5950 |
| 3R2715 | 3 | 270×150 | 830×150 | 15-20 | 2.3-2.8 | 1.8-2.8 | 0.9-1.7 | 22 | 8000×3500×4900 |
| 3R3016 | 3 | 300×160 | 880×160 | 15-20 | 2.6-4 | 1.9-2.6 | 1.0-1.9 | 30 | 6500×4100×5200 |
| 4R3216 | 4 | 320×160 | 970×160 | 20-25 | 3.2-4.5 | 2.4-3.1 | 1.8-2.5 | 37 | 9900×5800×10580 |
