Used Widely LSY Screw Conveyer Machine
- Qingdao
- T/T
You May Like
-
Popular QT12-15 Cement Brick Block Making Machine Price
-
2013 Hot Sale QTZ63B Tower Crane Electric Parts
-
China Best SS100/100 Building Material Lifter
-
Portable SS120 Construction Elevator Lifter
-
Used Widely DXBS30-13-56 Fine Aggregate Concrete Pump
-
High Performance JH50-21 Truck-mounted Concrete Pump
Product Details
| Condition | New | Type | Screw Conveyor | |
| Material | Stainless Steel | Material Feature | Heat Resistant | |
| Structure | Conveyor System | Load Capacity | 25~75t/h | |
| Place of Origin | Henan, China | Brand Name | UNIIQUE | |
| Model Number | LSY | Power(W) | 3~18.5kw | |
| Dimension(L*W*H) | 2.5~12.5m | Certification | ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
LSY Screw Conveyer Machine1.Compact form,small cross-sectional area
2.Good leak tightness
3.Hight transportation
LSY Screw Conveyer Machine
Descriptions of our Screw Conveyer Machine :
LSY type screw conveyor is special equipment that is in sealed circular section shell and continuous transport material via rotary palladium. It is used to transport a variety of meal, granular material, small block material, such as cement, fly ash and ore fines, etc. LSY screw conveyor has some features of compact form, small cross-sectional area, light-weight, good leak tightness, high transportation efficiency, flexible process collocation and so on. It adopts universal ball joint feed inlet, in order to be propitious to install, product and damp proof. It specially apply for transporting power material from concrete bin to mixer in concrete mixing plant.
Main Technical Parameters of our Screw Conveyer Machine :
Model | Length | Speed | Diameter | Angle | Capacity | Model | Power |
LSY 106-2.5 | 2.5m | 112 r/min | φ180mm | ≤20° | 25 t/h | Y100L2-4 | 3 kw |
LSY 160-4.5 | 4.5m | 112 r/min | φ180mm | ≤20° | 25 t/h | Y112M-4 | 4 kw |
LSY 200-6 | 6m | 100 r/min | φ219mm | ≤45° | 35 t/h | Y132S-4 | 5.5 kw |
LSY 200-8 (9) | 8 (9)m | 100 r/min | φ219mm | ≤45° | 35 t/h | Y132M-4 | 7.5 kw |
LSY 250-8 (9) | 8 (9)m | 90 r/min | φ273mm | ≤45° | 45 t/h | Y160L-4 | 15 kw |
LSY 300-9 (12.15) | 9 (12.15) m | 80 r/min | φ325mm | ≤45° | 75 t/h | Y180L-4 | 18.5 kw |
