Sell Mobile UTM40 Mini Ready-mixed Concrete Mixing Plants

Specifications

UTM-40 Mini Ready-mixed Concrete Mixing Plants

Descriptions of UTM-40  Mini Ready-mixed Concrete Mixing Plants :

The modular design without foundation and commissioning enables the mobile concrete mixing plant convenient movement and quick installation. It only takes three days from installation to use. All necessary facilities such as: control room, laboratory and maintenance room are equipped. Cost effective. It is an ideal choice for engineering.

General Information of UTM-40  Mini Ready-mixed Concrete Mixing Plants :

Capacity: 40 m³/h

Mixing Time: 60 S

Max Aggregate Size: 60/80 mm

Discharging Height: 3800 mm

Total Power: 75 kw

Total Weight: 17 Ton

Total Dimensions: 15000×4150×7800 mm

Transportation: Truck Trailer

Technical Parameters of UTM-40  Mini Ready-mixed Concrete Mixing Plants :

1. MIXING SYSTEM

Twin Shaft Concrete Mixer: JS750

Volume:1250 L

Capacity:750 L

Paddle quantity:16 pieces

Paddle Speed: 30.5 r/min

Mixing Motor: 37 kw

2. AGGREGATE SYSTEM

2.1Aggregate Batcher: PLD1200

Volume: 4×5m³=32

Sort of aggregate: 4

Capacity: 60 m³/h

Power: 7.5 kw

Sand vibrator: 0.37kw×2

2.2. Aggregate Belt Conveyor 1 unit

Width: 800 mm

Length: 18456mm

Speed: 1.6 m/s

Motor: 7.5 kw

3. CEMENT SYSTEM

3.1 Cement Silo  2 units
Capacity:50 Ton×2=100 Ton

Silo Diameter: Φ2800

3.2 Cement Screw Feeder     2 units

Diameter: Φ219 mm

Length: 9 m

4. ADDITIVE SYSTEM

Additive silo capacity: 1 m³

Pneumatic valve: Φ50 mm

Pump: 3kw

5. WATER SYSTEM

Submersible pump: 3kw

Water pump: 0.75kw

Water tank: 3 m³

6. AIR SYSTEM

Air Compressor: 1 unit

Power: 7.5kw

Pressure: 0.7Mpa

Air flew: 0.8 m³/min

7. WEIGHING SYSTEM

7.1 Aggregate weighing    1 unit

Weighing Capacity: 1.6 m³

Precision: ±2%

7.2 Cement weighing   1 unit

Weighing Capacity: 1m³

Precision: ±1%

7.3 Water Weighing   1 unit

Weighing Capacity: 150 kg

Precision: ±1%

7.4 Additive Weighing   1 unit

Weighing Capacity: 40 kg

Precision: ±1%

8. CONTROL SYSTEM:

PLC command and control operation

Main electrical components: Schneider

17’’ colorful computer

Manuel and Auto Control is freely changeable
