Home > Products > Drip Irrigation Tape Line > PE drip tape mould ( irrigation drip tape prodcution line)
PE drip tape mould ( irrigation drip tape prodcution line)
Negotiable
/ Set
1 Set(Min. Order)
- NINGBO
You May Like
-
Drip irrigation tape mould
-
Labyrinth drip irrigation belt production line( dia50,55,65mm single screw and barrel)
-
drip irrigation tape extruder with PE tape
-
Machine for PE drip irrigation tape
-
PE drip irrigation tape machine ( single screw and barrel dia50,55,60, 65mm)
-
PE drip irrigation tape for irrigation in cotton land
Product Details
| Place of Origin | Zhejiang, China | Brand Name | PUTUOSHAN | |
| Model Number | PTS | Shaping Mode | Plastic Extrusion Mould | |
| Product Material | Steel |
Product Description
Specifications
PE drip tape mould Dia382mm / Dia477.5mmMounting dimensions(between centers mm): 450.370
Mounting height(mm): 250
PE drip tape mould Dia382mm / Dia477.5mm
Performance,standard and technical parameter
-Outside dimension of moulds (mm): dia477.5mm
-Mounting dimensions(between centers mm): 450.370
-Mounting height(mm): ≥250
-Output(m/min): 55-65mmin
-Double moments rolling
-Length of monovolume(m): 500-2000
-Inside diameter(ID) of drip tape(mm): dia12-20
-Wall thickness of drip tape(mm): 0.16-0.24
-Space between water dropper of drip tape (mm): 250. 300. 500. 750
-Flow rate of water dropper(L/n): 1.2-4.0
-Oeviation of flow rate: ±5
-Operating pressure (Mpa): 0.1-0.18
