Hydraulic Aluminum Chips Briquetting Press Machine

FOB Price

US$ 10,000 - 20,000 / Set

1 Set(Min. Order)

Port shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	JINALL
Model Number	SBJ-3150		After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Hydraulic aluminum chips briquetting press machine Model SBJ-00C

This machine is used for cold pressing of other metal scraps including powdery grainy cast iron scraps, high grade ductile cast iron scraps, alloy scraps, steel scraps, copper scraps, etc. to columniform cakey block with the density ≥ 5.5~6.2T/m³ (without any bond). The output of the shift is 8~20Tons. This machine designed with vertical structure, upper & nether beams of cast steel, firmly and

trmtly with PLC controlling, auto charging, auto pressing, auto discharging themachine goes on in full automatically. It is very easy to operate.

Technical Data

Sr.no	Type name	unit	Model or data
Sr.no	Type name	unit	Main cylinder		Speed up cylinder	Side push cylinder	Materical cylinder
1	Nominal pressure	KN	2543		237	286	80
2	Inner diameter of cylinder	mm	Φ360		Φ110	Φ135	Φ80
3	Piston diameter	mm	Φ200		Φ70	Φ80	Φ45
4	stroke	mm	400		410	160	300
5	ure	Mpa	25		25	16	15
6	Head/bottom girder and cylinder	Four-column ,Cast steeling
7	Electrical motor	1pc		Y200L-4 30KW
8	pump	1pc		100MCY14-1B
9	efficiency	2~3pcs/minute (Al chips, each pc weight3~4kgs) 3.5pcs/minute (Steel chips, each pc weight 2.5~3kgs) 6pcs/minutes( Cast iorn HT200, each weight 3~4kg)
10	Briquette density	≥5.5Ton/M³(Cast iron chips) ≥6.0(Copper chips) ≥2.0 (Al chips)
11	Size of Mould	Φ90 (Cast irons chips) Φ120mm (Al chips)
11	Working efficiency	1000~1500kg/hour (Cast iron chips) 300~500kg /hour(Al chips, steel chips)
12	System controller	SIEMENS PLC ,ADJUSTABLE DISPLAY;INTERGRATION VALVE
13	COOL BY	7m² WATER COOLING, Automatic Temp controller
14	WEIGHT	6000Kg
15	OPERATED BY	MANUAL/PLC
16	Payment term	30% advance t/t ,balance by T/T before shipment.
17	MACHINE SIZE	BODY:2500×1000×3200mm OIL BOX:1600×1400×1900mm

After-Sales Service

Free product documents translation into your language, worry-free to operate and maintain
7x24 technical phone service
Engineers available to service machinery overseas
Customer database with all customers’ records in it.
10 years overseas sales experience
