2013 robotic lawn mower, garden lawn mower robot, automatic grass cutting machine

Place of Origin	Zhejiang, China		Brand Name	ICHRoboter
Model Number	Lion-2000		Power Type	Electricity
Type	Robotic Mowers		Feature	2-Stroke, Height Adjustable Handles
Certification	CE, Other, CE, RoSH, ISO 9001		Forward Speed	16-30m/min
Cutting Width	230mm, 230mm

Specifications

Easy to use & low consumption
Time switch, appointment mowing
Anti-theft function
Automatic protection with warning alarm





Principal Technical Parameters
Input Voltage	100~240VAC, 50~60Hz
Rated Power	200W
Walking Speed	16-30m/min
Cutting Width	230mm
Cutting Speed	120-200 m2 /h
Recommended Cutting Range	80-800 m2
Cutting Height Adjustment	35-65mm
Gradeability	27°
Battery Performance	1h/2h
Rechargable Li-on Battery	24~29V, 4Ah or 8Ah
Guaranteed Noise Level	≤75 dB
Grade of Waterproof	IP23
Optimum Storage Temperature	-10°C-45°C
Optimum Working Temperature	0°C-35°C
Relative Humidity	20%~75%
Optimum Storage Humidity	20%~80%
Dimension (L*W*H)	698*533*294mm
Packing Measurement	860*640*392mm
N.W/G.W	20.5/22.5kg
Certificate	CE, RoSH, ISO 9001
Payment: TT in advance



















Lion-2000 Features:

1.     Easy to use

Just choose the working cycle and press start, the mower will working automatically.



 2.    Lift & tilt sensor

The mower will stop working within 2~3 seconds once it lift from floor over 20mm or tilt over 30 degree, warning alarm will sound at the same time.



3.       Time switch, appointment mowing

Set up a mowing schedule, the mower will start working automatically at the appointment clock.



4.       Anti-theft function

User must enter the correct password then the mower can be started. Warning alarm will sound once the user enter the wrong password.



5.       Automatic stop

The mower will stop within 3 seconds once the virtual wire have problem or machine fall down and warning alarm will sound.



6.       The motors (both cutting motor and running motors)

All motors incorporate planetary motor technology. It has the operation time of 1500 hours. We only use the best technology available in the construction.



7.       Low battery sensor

Low battery sensor turn on once the battery lower than 10%, the mower will come back to the charging station for charging automatically.



8.       Rain sensor

The mower will come back to the charging station when raining.



9.   Ultrasonic sensor

The mower will automatic slow down the speed and change direction before bump people or obstacles automatically.



10.   Humanistic cutting height selection

Easy for user to choose the cutting height. 3cm-6cm humanistic design makes more choice of cutting height .
