Home > Products > MICROSCOPES > stereo microscopes
stereo microscopes
USD $150 - $1,000
/ Piece
5 Pieces(Min.Order)
- 2000 Piece / Pieces per Month
- SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | HG | |
| Model Number | LBX | Theory | Stereo Microscope | |
| Drawtube | Other |
Product Description
Specifications
WE CAN SUPPLY HIGH ACCURACY MICROSCOPESInformation
FEATURES
1.Sharp stereo erect image over a wide field of view
2.45°inclined and rotatable binocular head
3.The interpupillary distance is between55mm-75mm,The left ocular-tube with diopter adjustment±5dp
4.Inside incident light,brightness adjustable,various illumination for selection
5.Power supply 110V/60HZ or 220V/50HZ
duct has CE approval .
Technique data
| Program | data |
| Zoom ratio | 1:6.7 |
| Objective zoom range | 0.75x-5x |
| Eyepiece | SWF10xφ23 |
| Working distance | 113mm |
| Interpupillary distance adjustment | ≤55mm-75mm≥ |
| Diopter adjustment | ±5dioper |
| Binocular head viewing angel | Inclination of 45° |
| Binocular head rotating angel | 360° |
| Focusing range | 80mm |
| Lux of incident LED light | 6800lux |
| Lux of transmitted LED light | 2100lux |
Optical Data
| Main body | with0.5xobjective | with0.5xobjective | with2xobjective | ||
| 0.75x∼5x | 0.375x∼2.5x | 1.125x∼7.5x | 1.5x∼10x | ||
| 5x | Total magnification | 3.75x∼25x | 1.875x∼12.5x | 5.625x∼37.5x | 7.5x∼50x |
| Diameter of visual field | Φ33∼Φ5 | Φ65∼Φ10 | Φ22∼Φ3.3 | Φ16∼Φ2.5 | |
| 10x | Total magnification | 7.5x∼50x | 3.75x∼25x | 11.25x∼75x | 15x∼100x |
| Diameter of visual field | Φ33∼Φ5 | Φ65∼Φ10 | Φ22∼Φ3.3 | Φ16∼Φ2.5 | |
| 15x | Total magnification | 11.25x∼75x | 5.625x∼37.5x | 16.875x∼112.5x | 22.5x∼150x |
| Diameter of visual field | Φ24∼Φ4.2 | Φ48∼Φ8.5 | Φ16∼Φ2.8 | Φ12∼Φ2 | |
| 20x | Total magnification | 15x∼100x | 7.5x∼50x | 22.5x∼150x | 30x∼200x |
| Diameter of visual field | Φ20∼Φ3.5 | Φ40∼Φ7 | Φ13.3∼Φ2.3 | Φ10∼Φ1.8 | |
| 25x | Total magnification | 18.75x∼125x | 9.375x∼62.5x | 28.125x∼187.5x | 37.5x∼255x |
| Diameter of visual field | Φ15.8∼Φ2.4 | Φ31.5∼Φ4.8 | Φ10.5∼Φ1.6 | Φ7.9∼Φ1.2 | |
| working distance | 113mm | 220mm | 50mm | 35mm | |
