Submersible Pump Shaft

FOB Price

US$ 2 - 5 / Meter

500 Meters(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	YANGFINE
Model Number	model number YFH-28,30,32,36,42

Description: flexible shaft ,concrete vibrator shaft

Structure: 70#~75# high-carbon steel wire

Direction of Twist: Levorotation and dextrorotation

Applicable Scope: Vibrating machine, automobile, motorbike, counter, revolution counter, electric tools,

gardening machinery mower, and various mechanical flexible rotations.

Function: Smooth, flexible, highly-elastic, and wear resistant

Technical Parameters

Diameter (mm)	Tolerance (mm)	Number of Layers	Loading Moment (N · m) (Sample 500mm Long)	Weight (kg/ 100m)
2.0	+0.02 -0.02	3/5	0.8	1.8
2.5		3/5	1.0	2.8
3.2		3/5	1.3	4.6
3.8		3/5	1.5	6.5
5.0	+0.00 -0.05	3/4/5	1.8	11.3
6.0		3/4/5	2.4	16.2
6.5		4/5/7	2.9	18.7
8.0		4/5/6/7	7.5	28.8
10		4/5/6/7	22.5	45.5
12		4/5/6/7	39.0	66.5
13		4/5/6/7	50.5	77.5
16		4/5/6/7	115.0	114
18		4/5/6/7	160	145
The flexible shafts not listed in the chart can be customized

Values:

1.Welcome to visit factory warmly. can send samples for testing in advance.

2.can supply OEM service with your own logo.

3.Supply high quality & the most competitive price for you,

4.Our products have passed ISO9001_2008,CE, CCC certifications, etc, and the quality is

internationally recognized.
