High Frequency Motor-in-head Concrete Vibrator
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | YANGFINE | |
| Model Number | YFA-52mm | Type | Internal | |
| Drive Mode | Electric Vibrator | Vibrating Amplitude | minimum 1mm |
Product Description
YANGFINE BRAND MOTOR--IN --HEAD CONCRETE VIBRATOR
The concrete vibrator have stronger centrifugal force ,bigger ampltude,higher frequency,lower consumption than the traditional vibrator ,and it is very easy to operate only by one person .The YANGFINE brand vibrator use a advanced technology and manufature
The concrete vibrator ccan be used in variety of construction filed ,and the 20v voltage can be avoid .
For the maximum performance of the equipment,we recommend to read carefuuly the safety recommendations,and usage listed in this manual,Defective partsshould be replaced immediately to avoid mayor problems.
'We will glad to help you with any comments or suggestions in reference to our equipment .
Poker diameter (mm) | 52mm |
Poker length (mm) | 395mm |
Poker weight (kg) | 4.5kg |
Hose diameter (m) | 36mm |
Hose length(m) | 4m |
Total weigth(kg) | 13kg |
Cable type | 3x1.0mm2(H05RN) |
Cable length: | 20m |
Input Current | Max 8A |
Input power | Max 1.25kw |
Input Voltage/Frequency | Ac220v--240v/50hz |
Output Frequency | 200HZ |
R.P..M | 12000 |
Amplitude | Minimum 1mm |
Centrifugal Force | Max 380kgf |
Application Temperature | -10 ? -40 ? |
IP Code | Poker IPX8 |
| Converter IPx5 |
