Home > Products > Flexible shaft submersible pump > Submersible Pump Hose
Submersible Pump Hose
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | YangFine | |
| Model Number | YFH-30 |
Product Description
Flexible rubber hose Usage:
be extensive used in vibration machinery,garden machinery,water pump .can be used for all the non-linear motion machine.
Technical parameters:
Model | Outer.dia | Inner.dia | Rubber tensile | Adhensive of inner rubber | Steel belt material | Steel belt hardness | Rubber hardness | Steel wire braid | Min.bending radius(mm) |
YFH-16 | 16mm | 9mm | >1000 N/ | 50-60 N/ | 40Mn-65Mn | 20HRC-30HRC | 50-62 | 1 | 75 |
YFH-20 | 20mm | 10mm | 1 | 80 | |||||
YFH-22 | 22mm | 10mm | 2 | 80 | |||||
YFH-24 | 24mm | 13mm | 60-65 | 20Mn-65Mn | 75-80 | according to the demand | 100 | ||
YFH-30 | 30mm | 16mm | 120 | ||||||
YFH-32 | 32mm | 18mm | 150 | ||||||
YFH-36 | 36mm | 20mm | 200 | ||||||
YFH-42 | 42mm | 25mm | 250 |
Our advantage
1. can be coupled to electric motors,,gasoline engines,diesel engines,flexible shaft pumps
2. no mini order demads
3. can supply OEM service with your own logo
4. can send sampales for testing in advance, welcome to visit factory warmly
5. can supply the most competitive price with the high quality for you: all flexible shafts c/w rubber hoses and all connectors for concrete vibrators,are manufactured by ourselves
6. can supply or assemble the semi-products concrete vibrator for you.
YFH series Flexible hose Features
1. is widely used in vibration machinery,garden machinery and water pumps and other mechanical products.can be used for all the non-linear motion machine.
2. it was made of rubber,stee-wier net,canvas,lining sping.
3. flexible rubber hoses are extensive used to the flexible tansmission of various machinery,such as the vibrator equipment,garden machine, water pump and other mechanical products.can be used for all the non-linear motion machine.
4. it was made of rubber,stee-wier net,canvas,lining sping.
Contact Us
- Liaocheng Yangfine Jeonil Machinery Co., Ltd.
- Contact nameDaliya Sun Chat Now
- Phone86-635- 2921122
- AddressNo.69 Huaihe Road ,Economic Development Area ,Liaocheng ,Shangdong ,China, Liaocheng, Shandong
