Auto copy moulder SHX6232X200 with Max. working length 2000mm and Max. Working width 360mm
Negotiable
/ Piece
1 Piece(Min.Order)
- 100 Piece / Pieces per Month
- QINGDAO PORT
You May Like
-
Auto copy moulder SHX6232X150 with Max. working length 1500mm and Max. Working width 360mm
-
Plywood and Door Edge Cutting Machine for 4 sides SH4SJ105X210 with Max working width 700---1110mm and Max. Working Length 2400m
-
Laminating Product Line For PUR Glue SH1350PURM with Max.panel width 1220mm and Max.feeding speed 15m/min
-
Auto Stacking Machine SH2512-II with Worktable size 2500x1200mmm and Min. panel thickness 3mm
-
Auto Feeding Machine SH2512-I with Worktable size 2500x1200mm and Min. panel thickness 3mm
-
CNC Boring Center Machine with Five Sides SHCNC-FSB2500 with Max. speed 80m/min and Main spindle power 3.5KW
Product Details
| Condition | New | CNC or Not | Normal | |
| Place of Origin | Shandong, China | Brand Name | SHOOT | |
| Model Number | SHX6232X200 | Power(W) | 5500Wx2pcs/3700W | |
| Dimension(L*W*H) | 3960x1900x2050mm | Weight | 3500kg | |
| Certification | CE |
Product Description
| Auto copy moulder | |
| Model | SHX6232X200 |
| Max. working length | 2000mm |
| Max. Working width | 360mm |
| Max. Working thickness | 140mm |
| Spindle Dia. | 30mm |
| Wheel Dia. | 90mm/ 100mm |
| Spindle speed | 9000r/min |
| Spindle power | 5.5kwx2pcs |
| Hydraulic motor power | 3.7kw |
| Table size | 2200x285mm |
| Air pressure | 0.6-0.8MPa |
| Hydraulic system pressure | 8MPa |
| Dust collection duct Dia. | 100mmx2pcs |
| Overall size | 3960x1900x2050mm |
| N.W. | 3500kg |
