YXS2001WV-06P 2.0mm Straight needle holder connector

Specifications

Specifications :
Current Rating : 2A AC,DC
Voltage Rating : 200V AC,DC
Temperature Range : -25 deg C ~+85 deg C
Contact Resistance : 20m Omega Max.
Insulation Resistance : 1000M Omega Min.
Withstanding Voltage : 800V AC/minute
*Contact YXS2001 for detals*

Housing
Part No:YXS2001H-
Poles:2-16P.
Material:Nylon66 UL94V0 or UL94V2
Packing Q'TY:1000pcs/bag
Mates With YXS2001T  Series Terminal

Terminal
Part No:YXS2001T
Thickness:0.20mm
Material:Phosphor bronze/ Brass
Finish:Tin Plated
Wire Range:AWG#24-#28
Insulation O.D. : 1.20mm ( Max.)
Q'TY:10,000pcs/reel
Mates WithYXS2001H- Series Housing

Wafer (DIP and SMT Type)
part No:YXS2001WV/WR-NP  or SCT2001WV/WR-S-NP
poles:2-15P
Material:Nylon6T UL94V-0
Packing Q'TY:1000pcs/box
Mates WithYXS2001H- Series Single Row Housing
