YXS1251H-05P write to write connector

Specifications

"Specifications :
Current Rating : 1A AC,DC
Voltage Rating : 250V AC,DC
Temperature Range : -40 deg C ~+85 deg C
Contact Resistance : 20m Omega Max.
Insulation Resistance : 100M Omega Min.
Withstanding Voltage : 500V AC/minute
*Contact YXS for detals*"

Housing
part No:YXS1251H-
poles:2-16P
Material:Nylon66 UL94V-0
Packing Q'TY:1000pcs/bag
Mates With YXS1001WV- Series Single Row Wafer

Terminal
Part No:YXS1251-T
Thickness:0.15mm
Material:Phosphor bronze
Finish:Tin Plated
Wire Range:AWG#28-#32
Insulation O.D. : 0.8mm
Q'TY:15,000pcs/reel
Mates With YXS1251H- Series Housing

Wafer  (DIP and SMT Type)
part No:YXS1251WV/WR-1*NP  or YXS1251WV/WR-S-1*NP
poles:2-16P
Material:Nylon46/6T UL94V-0
Packing Q'TY:1000pcs/box
Mates With YXS1251H- Series Single Row Housing
