Best price YQBJ-300x200 Hydraulic Rail Lifting and lining machine
- 0 per Month
- da lian port
- T/T
You May Like
-
Top rated sleeper adjustor
-
Top selling YFZ-80 Hydraulic sleeper adjustor
-
Top products hot selling new 2015 5t~10t rail mechanical jack for lifting
-
SCQ-200 New design machine sale good price hydraulic bottle jack handle
-
SCQ-200 Factory directly sale railway favorable pricing in marketing mini hydraulic jack
-
YB-200 type Hydraulic rail lining device
Product Details
| Brand Name | tiegong | Model Number | YQBJ-300x200 | |
| Certification | ISO 9001 | Warranty | 1 year |
Product Description
Specifications
It's a special tool employed in the lifting & lining operation of railway overhaul,medium maintenance and track bed maintenance.
Its structure is reasonable.Whiile hydraulitc system falls down.Manual pump can be used to operate or moved the machine off-track to ensure safe operation.The open & close of the rail hook happens at the same time while the up & down of the main frame takes place to depending on the rail weight simply,reliably and safely...It's a special tool employed in the lifting & lining operation of railway overhaul,medium maintenance and track bed maintenance.It's suitable for rail of 13kg/m-75kg/m lifting & lining operation.By using it ,the rail can be lifted as well as level regulated.It possesses feature of high workingeffciency,simple manipulation,light weight,reduction of labor intensity,safety & reliablity and wide application.
Quick Details
| Place of Origin: | Liaoning China (Mainland) | Brand Name: | TieGong | Model Number: | YQBJ-300*200 |
| Lift Mechanism: | Screw Lift | Lift Drive / Actuation: | Hydraulic | Power: | 9.5KW |
| Rated Loading Capacity: | 150KN | Overall Dimensions: | 2050 x 1050 x 1360 | Weight: | 600KG,600 kg |
| Certification: | CRCC | Warranty: | one year | After-sales Service Provided: | Overseas third-party support available |
| rated track force single cylinder: | 150kn | double cylinder: | 150kn*2 | lifting cylinder stroke: | 800 mm ± 5 mm |
| rated dial the way force: | 200 kn | dial the way quantity: | >=160 mm | system working pressure: | 16 mpa |
| manual pump operation force: | 350 n | engine power: | 9.5 kW | volume: | 2050 x 1050 x 1360 |
Packaging & Delivery
| Packaging Detail: | plywood case or base on customer's need |
| Delivery Detail: | 15 days after recieved payment |
Specifications
Easily handle by two workers of lifting machine:
1. lifting cylinder stroke: 800 mm +5 mm
2, rated dial the way force: 200 kn
Specifications
1.Rated track force: single cylinder 150 kn
Duplex 150 kn x 2
2.weight:600kg
3. CRCC
Detailed Production describe:
1ISO9001
2.PATENT
3.CRCC
YQBJ-300 type 30T Hydraulic lifting&lining machine
Acope of application:
YQBJ - 300 x 200 type hydraulic up dial the word machine, is the railway line, repair and ballast bed maintenance track, dial the way special equipment, suitable for 43 kg/ m ~ 75kg / m rail line track, dial the way homework, can drive up and can adjust track level operation. Has the working efficiency high, the operation is simple, portable, lighten physical labor, safe and reliable, widely used, etc.
Main technical parameters
1, rated track force: single cylinder 150 kn
Duplex 150 kn x 2
2, lifting cylinder stroke: 800 mm ± 5 mm
3, rated dial the way force: 200 kn
4, dial the way quantity: >=160 mm
5, system working pressure: 16 mpa
6, manual pump operation force: 350 n
7, engine power: 9.5 kW
8, volume (LWH) : 2050 x 1050 x 1360
9, weight: 600 kg
