Vibration Grinding Mills
- xingang
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Other, cup mill | |
| Motor Type | AC Motor | Power(W) | 1500 | |
| Capacity(t/h) | 1 | Brand Name | C-Tech | |
| Dimension(L*W*H) | 650*600*960mm | Weight | 180 | |
| Warranty | One Year | After-sales Service Provided | Overseas third-party support available |
Product Description
C-Tech vibration mills offer the full benefits of program – controlled grinding processes for the preparation of samples for x – ray fluorescence analysis. Control by programmable controller results in a substantial improvement in the reproducibility of sample preparation and consequently optimum analysis results.
Vibration grinding mills are suitable for the grinding of minerals, slags, ferro alloys, organic substances and other materials. The high speed of the drive motor enables even hard material to be ground with short process times. The robust design with twin eccentric disk bearings enable the grinding mills to achieve a long service life with a minimum of maintenance.
the grinding processes on the vibration mills are controlled reliably by a plc program. This eliminates incorrect handling or settings as sources of errors. The parameters can be accessed only through a password.
grinding vessels for a range of applications, with capacities of 10, 50 and 100 ml (steel and tungsten carbide) and 100 ml (agate) are available.
Manually operated clamping facility for the grinding vessels
C-Tech vibration grinding mills are fully encapsulated, insulated against noise, and have safety cut-outs for operator protection. The dust and noise burden at the workplace is therefore reduced considerably and the safety enhanced.
C-Tech vibration grinding mills are high-quality, precision engineering products with compact dimensions, and are therefore ideally suited to laboratory requirements.
The design of the machines correspond to the current german accident prevention and vde regulations. We reserve the right to make technical changes.
Type | ZHM-1A | ZHM-1B | ZHM-1T | ZHM-1V | ZHM-3B |
Feature | Single-speed, Single-vessel | Single-speed, Single-vessel | Two- speed, Single-vessel | Frequency conversion, Single-vessdl | Single-speed, Three-vessel |
Charging granularity | ≤5mm | ||||
Discharging granularity | ≤80μm | ||||
Vessel cubage | 100cm3 | ||||
Fill sample | 20-70gram | (20-70)×3 | |||
Vessel material | Tungsten carbide, Chrome-steel, Manganese-steel | ||||
Power supply | AC380V±10%/50Hz/3-phase+earth | ||||
Rotate speed | 1400r/min | 960r/min | 910/1400r/min | 750-1550r/min | 960r/min |
Rated power | 1.5KW | 1.5KW | 0.85/1.1KW | 1.5KW | 2.2KW |
Dimension | 650×600×960mm | 710×810×1080mm | |||
Net weight | 180kg | 180kg | 180kg | 180kg | |
Ambient temperature | 5-40°C | ||||
