GC-150 Asphalt plate gyratory compactor machine
- 200 Set / Sets per Month
- Ningbo Shanghai Negotiable
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | GEOTEST EQUIPMENT, GEOTEST EQUIPMENTS | |
| Model Number | GC-150, GC-150 | Power | Electronic | |
| Usage | Other, Asphalt plate gyratory compactor machine |
Product Description
Asphalt plate gyratory compactor machine
Standard: AASHTO T312, ASTM D6925, EN 12697-10, 12697-31
These standards specify the methods for compaction of cylindrical specimens of bituminous mixtures using a gyratory compactor. Such compaction is achieved by combining a rotary shearing action and a vertical resultant force applied by a mechanical head.
The method can be used for:
a. the preparation of specimens of given height at a pre-determined density, for subsequent testing of their mechanical properties;
b. the derivation of a curve density versus number of gyrations;
c. the void content for a given number of gyrations
| ||||||
| Compacted specimen size | diameter 150 and 100mm, height from 30 to 170mm | |||||
| Gyrator displacement | 0-250mm, accuracy: 0.10mm | |||||
| Gyrator angle | easily adjustable from 0° to 2.0° (adjustable, pre-set 1.16°) | |||||
| Pressure range | 100-1000KPa (adjustable, pre-set 600KPa) | |||||
| Gyrator rate | 50 cycles/minute (adjustable, pre-set 30 cycles/minute) | |||||
| Number of cycles (gyrator) | 0-999 | |||||
| Loading pressure method | pneumatic | |||||
| Overall dimensions | 900x700x1800mm | |||||
| Weight approx | 400kg | |||||
Asphalt plate gyratory compactor machine
Asphalt plate gyratory compactor machine
The biggest manufactor is in china, the top quality is in china, the best service is also in china!
Pls believe GEOTEST, Believe China Power!
We sincerely lookinf forward to cooperate with you!
