1.2cbm Low Cost Small Mobile Self Loading Concrete Truck Mixer Sale
- Qingdao Tianjin Shanghai
- T/T Credit Card
You May Like
-
New Design High-efficiency Mini Self Loading Concrete Mixer Truck 1.2CBM
-
Factory Price 4 Cubic Meter Self Loading Concrete Mixer Truck
-
High Efficiency Self Loading Concrete Mixer Truck Used in Cement Mixing
-
High Quality 2.0cbm Self Loading Concrete Mixer Truck With Electronic Weighing
-
Rotary Self Loading Cement Mixing Truck Mini Mobile Concrete Mixer Truck
-
2 Cubic Meter Mini Self Loading Mobile Concrete Mixer Truck for Sale
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | HW | Model Number | HWJB120 | |
| Weight | 3200kg | Dimension(L*W*H) | 5 *1.9 m*2.6m | |
| Power(W) | 85 kw | Certification | ISO CE | |
| Warranty | 1 Year | After-sales Service Provided | No overseas service provided |
Product Description
1.2cbm Low Cost Small Mobile Self Loading Concrete Truck Mixer Sale Introduction
Concrete mixer truck(cement mixer, concrete mixer), is specially used for transportation of concrete. Because of its appearance, often referred to as snail truck. There is a mixing drum on the truck and it keep on mixing during transportation to avoid solidification of concrete. After the concrete is output, it is usually water washed inside, to prevent hardening of the concrete, and taking up the space of drum.
mobile concrete mixer truck Features
- Automatic feeding
- Electronic weighing
- Self-stirring
- Walkable
- Without mixing station
- Four-wheel drive
- 1 ~3 m3 capacity
- Customizable and export-oriented
- we have 1 to 4 m3 mixed capacity for your choose
1.2cbm Low Cost Small Mobile Self Loading Concrete Truck Mixer Sale Parameter
Mixing System | Drum capacity 1.7 m³, height of 1.5 meters discharge . |
Production capacity | Concrete output: 1.2 m³/ cans, 4.8 m³ / h |
Engine | Wuxisida brand with 490 boost , 48KW |
Yunnei brand with 490 boost , 48KW(optional) | |
Transmission | Torque converter, 4-wheel drive, two steering, Chinese Axle |
Walking speed | Low speed 2 km / h high-speed 20 km / h |
Cab | Left-hand drive, anti-tilt, FOPS cab, front loading shovel |
Hydraulic system | Domestic hydraulic systems, open loop for hydraulic transmission and drum rotation |
Operating lever | Electronically controlled four-speed joystick |
Bucket | 270 liters, hydraulic valve |
Chute | Hydraulic adjustable angle, in order to increase the discharge length |
Water supply system | Hydraulically driven self-priming pump, washing with high pressure water pump vehicle, electronically controlled self-priming pump, take 100 kg water per minute |
Brakes | Air brake brakes, dual independent circuits |
Tire | 12-16.5 construction machinery tires |
Power Systems | 24V |
Tank | Fuel tank: 35 liters, hydraulic tank: 120 l |
Weight | 3200kg |
Dimensions | Length: 5 m Width: 1.9 m Height: 2.6 m |
Measure | Electronic weighing, measuring water control, recipe controlled |
1.2cbm Low Cost Small Mobile Self Loading Concrete Truck Mixer Sale Photos
