Brand New SINOTRUK HOWO Heavy Duty Concrete Mixer Trucks 8x4

Engine Model

WD615.69

Kerb Weight (Vehicle/Chassia)

12800/8650 kg

Fuel Tank Capacity

300 L

Payload (Vehicle/Chassis)

14500/10660 kg

Axle base

1800+3200+1350 mm

Front/rear suspension (Vehicle/Chassis)

1500/(2300/1300) mm

Wheel base (Front/Rear)

2041/ 1850 mm

Mini ground clearance

314 mm

Approach/departure angle (Vehicle/Chassis)

16/(18/35) Degree

Max.speed

75 km/h

Max climbing capacity

>50%

Mini turning circle

23.7m

Reclaiming Capacity

12;14 cubic meter

Front Axle

HF9, load capacity 9 ton, drum

Driving Axle/Rear Axle

HC16 double reduction(central single reduction with different locks between wheels and axles

Cabin(Volvo Technology)

HW70 standard cabin,no sleeper;   up and down,front and back adjustable steering wheel;   double locking structure belts

Steering System(ZF)

ZF power steering, model ZF8098, ZF steering oil pump,         system pressure 18MPa

Brake(Wabco)

Service brake: dual circuit compressed air brake

Parking brake(emergency brake):sping Energy,copressed air operating on rear wheels.

Auxiliary brake:engine exhaust brake Option:ABS,EVB

Wheels & Tyres

12.00-20;option:11.00-20
