Powder Forming
US$ 1,000 - 50,000
/ Unit
1 Unit(Min. Order)
- Shanghai port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | SMAC | |
| Model Number | YAN |
Product Description
Main parameters
11818 | 11819 | 11820 | 11821 | 11822 | 11823 | 11824 | |||
Item | (Unit) | YAN79Z -40 | YAN79Z(K) -63 | YAN79Z(K) -100 | YAN79Z(K) -200 | YAN79Z(K) -315 | YAN79Z(K) -500 | YAN79Z(K) -630 | |
Nominal Pressure | kN | 400 | 630 | 1000 | 2000 | 3150 | 5000 | 6300 | |
Push-up force | kN | 280 | 350 | 400 | 850 | 1000 | 1400 | 2000 | |
Max. pressure of liquid | MPa | 25 | 25 | 25 | 25 | 25 | 25 | 25 | |
Slide-stroke | mm | 350 | 400 | 400 | 500 | 500 | 600 | 600 | |
Push-up stroke | mm | 150 | 200 | 200 | 250 | 250 | 300 | 300 | |
Daylight | mm | 120 | 120 | 150 | 150 | 150 | 150 | 150 | |
Fast down | mm/s | 120 | 120 | 120 | 100 | 100 | 100 | 100 | |
Slow down | mm/s | 20 | 18 | 15 | 12 | 12 | 12 | 12 | |
Speed | Return | mm/s | 100 | 120 | 100 | 80 | 60 | 80 | 60 |
Push-up | mm/s | 48 | 40 | 40 | 40 | 35 | 40 | 40 | |
Return | mm/s | 48 | 45 | 45 | 45 | 45 | 45 | 40 | |
Up-oil cylinder | Max. pressure | kN | 8 | 11 | 11 | 18 | 18 | 22 | 22 |
(Coption) | Max. return pressure | kN | 4.5 | 5 | 5 | 9.5 | 9.5 | 11 | 11 |
Max. stroke | mm | 30 | 30 | 30 | 30 | 30 | 30 | 30 | |
Max. pressure | kN | 30 | 30 | 60 | 80 | 80 | 120 | 120 | |
Down-oil cylinder | Max. return pressure | kN | 10 | 10 | 35 | 50 | 50 | 60 | 60 |
Max. stroke | mm | 100 | 100 | 120 | 200 | 200 | 200 | 200 | |
Table size | mm2 | 450x450 | 560x490 | 700x580 | 950x700 | 1120x800 | 1200x1000 | 1300x1000 | |
Power moving | Max. pressure | kN | 80 | 80 | 80 | 80 | 80 | 125 | 125 |
cylinder option | Max. stroke | mm | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
Driving cylinder for | Pressure | kN | 45 | 45 | 45 | 45 | 45 | 65 | 65 |
flooating die-frame | Max. stroke | mm | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
Ass. cylinder | Max. pressure | kN | 20 | 23 | 23 | 25 | 25 | 27 | 27 |
Max. stroke | mm | 30 | 30 | 30 | 30 | 30 | 30 | 30 | |
Main motor | kW | 7.5 | 7.5 | 11 | 15 | 22 | 30 | 37 | |
L-R | mm | 1760 | 1800 | 3010 | 4200 | 4575 | 5775 | 5820 | |
Overall size | F-B | mm | 2310 | 2400 | 1300 | 1700 | 2425 | 2500 | 2630 |
Over-floor | mm | 3500 | 3600 | 4000 | 4500 | 4800 | 5200 | 5700 | |
Bellow floor | mm | 400 | 600 | 600 | 1500 | 1500 | 1700 | 1900 | |
Side- | Max. pressure | kN | 30 | 30 | 30 | 30 | 30 | 80 | 80 |
cylinder(Coption) | Max. return pressure | kN | 19 | 19 | 19 | 19 | 19 | 50 | 50 |
Max. stroke | mm | 60 | 60 | 60 | 80 | 80 | 80 | 80 | |
