Hydraulic deep drawing press Machine

Description:

1. Y27 Series Frame-type Hydraulic Press is a kind of multifunctional precision machine which has high speed.

2. Optimized design, the frame is entirely welded with steel plates, and treated to relive stress by tempering for high precision.

3. Cartridge valve equipped for hydraulic control system, reliable, durable and less hydraulic shock, shorter connection pipeline and fewer release points.

4. Centralized button control system, with adjustment, hand and semi-auto operation modes at operator’s choice (set-stroke single and set pressure single).

5. Four-angle and eight-side guide rail in high precision and with strong capacity against deflection, concentrated lubrication.

6. New type of oil cylinder sealing components marked by high reliability and long service life.

7. Sliding blocks operating in high speed, ensuring high efficiency.

8. The slide operating pressure, no-load quick travel and low-speed movement can be adjusted according to technological requirements.

9. Hydraulic cushion is fitted beneath the worktable; adequate knockout hole and hydraulic cushion are prepared on the plate of worktable with the operating modes including drawing, ejection and no ejection.

10. The working speed of this equipment is 3 to 4 times faster than that of Y41. It employs eight-side guide device and ejecting device, which can automatically eject workpieces with accurate guiding and fast speed.

11. The drawing device can be added to this equipment in order to change moulds easily. But the stretching of large metal parts needs to add hydraulic cushion to this equipment.

Main parameters:
