Composite Geomembrane for Slope Stabilization

Specifications

Composite Geomembrane for Slope Stabilization

Product Description

  Compound geomembrane is a non-woven complex geomembrane, using non woven geotextile as the base,and polyethylene (PE),PVC membrane, etc. as membrane materials. The product is formed after the processes of calendering, spreading and rolling.

Products Features

1.High strength,excellent tenacity

2.Anti-aging,anti-acid and alkali

3.Creep, corrosion and abrasion resistance

4.Excellent drainage, separation,filtration,reinforcement and seepage-proofing performance.

5.Safe and easy for construction

Product Specification

1.One piece of geotextile and one piece of membrane:

Weight of base geotextile:100-1000g/m²;Thickness of geomembrane :0.1-1.5mm

2.Two pieces of geotextile and one piece of membrane:

Weight of base geotextile:80-600g/m²;Thickness of geomembrane: 0.2-1.5mm

3.One piece of geotextile and two pieces of geomembrane:

Weight of base geotextile :100-1000g/m²;Thickness of geomembrane :0.1-0.8mm

4.Multi-layers:

Weight of base geotextile :100-1000g/m²; Thickness of geomembrane :0.1-0.8mm

Packing Specification

Width:2-6m  Length:50-100m (customized)

Technical Parameters of Compound Geomembrane

                                                                        GB/T17642-2008

Application range

• Slope stabilization
• Retaining earth structure
• Embankment on soft soil
• Foundation cushioning
• Basal reinforcement over pile foundation
• Stabilization of landfill slope
• Reinforcement on road construction
• Container yard
