Drainage Mat for Retaining Wall
- Within 12 days
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Starring | |
| Material | Other, HDPE | Thickness | 10-60mm | |
| Size | 1220*2440mm |
Product Description
Description
It is a kinds of geomembrane with dimples on the surface. The dimples can be in cylinder and semicone shape. It could also be coated by non woven geotextile. The liquid and gas can go through freely between dimples.
Drainage plate is made of polyethylene (HDPE) plastic floor with stamp
ing of cone or stiffening rib protruding point (or hollow
cylindrical porous). Width: 3-5m Roll length:30 -50m
Function:
• Drainage property
• Sound insulation&moistureproof
• protective property
• Auxiliary waterproof property
Property
1.Waterproofing and drainage:from a channel, which water and gas can go through
2.Sound insulation and vibration isolation
3.Chemical resistance, resist to plants' root
4.Easy for construction
5.Long lifetime
Application
1.HIghway and railway waterproofing system
2.Underground waterproofing
3.Roof garden waterproofing projects
Technical parameters
Item | 103 | 104 | 105 | 106 | 107(1) | 107(2) | 108 | 109 |
Corlor Floor | Black/White | Black/White | Black/White | Black/White | Black/White | Black/White | Black/White | Black/White |
Material | HPIS | |||||||
Quality (g/m2) | 760 | 820 | 3600 | 1000 | 1100 | 1200 | 1300 | 1600 |
Thickness(mm) | single10 | Duplex18 | Iniection18 | single20 | single25 | Duplex25 | single30 | single40 |
Anti-pression strength(kpa) | 400 | 200 | 1200 | 320 | 260 | 200 | 280 | 260 |
Geotextile color filter layer | Black/White | Black/White | Black/White | Black/White | Black/White | Black/White | Black/White | Black/White |
Material | Polypropylene and polyester | |||||||
Pore diameter(mm) | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 |
Water | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 |
Tenlile Strength(N) | 278 | 278 | 278 | 278 | 278 | 278 | 278 | 278 |
Quality (g/m2) | 150 | 150 | 150 | 150 | 150 | 150 | 150 | 150 |
Draiage Board specifactions | 1.2*16.6m | 1.2*16.6m | 1.2*16.6m | 1.2*16.6m | 1.2*16.6m | 1.2*16.6m | 1.2*16.6m | 1.2*16.6m |
Flow(L/S) | Tongji University hadraulic laboratory testing | |||||||
Head loss 5cm | 1.6 | 2.4 | 3.5 | 2.9 | 3.2 | 3.2 | 4.2 | 4.6 |
loss deduction 10cm | 2.2 | 3.2 | 5.2 | 4.2 | 4.6 | 4.6 | 6.4 | 7.2 |
