100g/m2 Filament Spunbond Nonwoven Geo Fabric Geotextile for Road
- 400 Square Meter / Square Meters per Month
- Qingdao
- T/T
You May Like
-
Road Construction Filament Spunbond Needle Punched Geotextile
-
PET Filament Spunbond Needle Punched Geotextile Fabric Price
-
Filament Spunbond Non-woven Geotextiles Fabrics for Sewage Treatment
-
Filament Spunbond Nonwoven Geotextile High Strength
-
Filament Spunbond Nonwoven Geotextile Fabric for Retaining Wall
-
Puncture Resistance Filament Spunbond Needle Punched Nonwoven Geotextile
Product Details
| Place of Origin | Shandong, China | Brand Name | STARRING | |
| Model Number | FNG | Geotextile Type | Non-Woven Geotextiles |
Product Description
Specifications
100g/m2 Filament Spunbond Nonwoven Geo Fabric Geotextile for Road1.Puncture resistance
2.Large elongation before breaking
100g/m2 Filament Spunbond Nonwoven Geo Fabric Geotextile for Road
Products Description
PET filament spunbond nonwoven geo fabric geotextile fabric is made by (Dacron PET), featured with good physical property, high tensile, resisting tearing, bursting, stabbing etc. It can effectively prevent the impact of irregular stones on the fabric and boasts excellent drainage,separation,filtration,protection and reinforcement performance.
Technical Specification
item
| Value
| ||||||||||
Nominal breaking strength /(KM/m) | 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | ||
1 | Breaking strength(MD/CD)(KN/m) | 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | |
2 | Elongation at break (MD/CD)/% |
40-80 | |||||||||
3 | CBR mullen burst strength KN≥ | 0.8 | 1.6 | 1.9 | 2.9 | 3.9 | 5.3 | 6.4 | 7.9 | 8.5 | |
4 | Tear strength/KN | 0.14 | 0.21 | 0.28 | 0.42 | 0.56 | 0.70 | 0.82 | 1.10 | 1.25 | |
5 | Sieve size O90 mm | 0.05-0.20 | |||||||||
6 | Vertical permeability coefficient cm/s | K×(10-1-10-3)K=1.0-9.9 | |||||||||
7 | Thickess/mm ≥ | 0. 8 | 1.2 | 1.6 | 2.2 | 2.8 | 3.4 | 4.2 | 5.5 | 6.8 | |
8 | Width variation% | -0.5 | |||||||||
9 | Weight variation | -5 | |||||||||
Note:
1. Specifications according to the unit area quality, the actual specifications in the range of two adjacent table, according to the interpolation method to calculate the appropriate evaluation specification; Beyond the scope of the table, the assessment specification to be negotiated by the supplier and buyer.
2. The standard value by design or agreement.
3. Above targets data if the changes without notice.
4. We can produce other specifications production according to users requirement.
Application Range
Used in the area of highway, railway, dam, coastal beach for rein forcement, filtration, separation and drainage,
especially used in salt marshes and garbage burying field.
Coastal, River & Flood Protection Works
