Home > Products > UHMWPE Rope > Ultra-High-Molecular-Weight Polyethylene UHMWPE Rope
Ultra-High-Molecular-Weight Polyethylene UHMWPE Rope
- 0 per Month
You May Like
Product Description
Product Name :XCMAX rope
Material :UHMWPE
Color : Golden
Products Description :
Ultra High Molecular Weight Polyethylene Ropes float in water making them significantly safer, their low stretch properties provide greater sensitivity and their low elongation combined with their low weight makes their handling easy and the manoeuvring of vessels extremely accurate especially in distress & critical times.
Application : mooring line, anchor line, towing rope, lifting sling, tug rope
Length per coil: 220m
Spliced strength: ±10% lower
Weight and length tolerance: ±5%
MBL: ISO 2307 standard
Other sizes can be customized
Parameter Table:
| | |||||
| dia | cir | weight | mbl | ||
| mm | inch | kgs/100m | lbs/100ft | ton | kn |
| 6 | 3/4 | 2.3 | 1.5 | 3.16 | 31.6 |
| 8 | 1 | 4 | 2.5 | 5.18 | 51.8 |
| 10 | 1–1/4 | 6.1 | 37 | 7.94 | 79.4 |
| 12 | 1–1/2 | 8.7 | 5.3 | 13 | 130 |
| 14 | 1–3/4 | 11.7 | 7.1 | 15 | 150 |
| 16 | 2 | 15.1 | 9.2 | 19.6 | 196 |
| 18 | 2–1/4 | 19 | 11.6 | 24.3 | 247 |
| 20 | 2–1/2 | 23.2 | 14.3 | 30.2 | 302 |
| 22 | 2–3/4 | 28.1 | 17.2 | 35.9 | 359 |
| 24 | 3 | 33.1 | 20.4 | 42.1 | 421 |
| 26 | 3–1/4 | 38.4 | 24 | 48.3 | 483 |
| 28 | 3–1/2 | 44.5 | 27.8 | 55.1 | 551 |
| 30 | 3–3/4 | 50.6 | 31.8 | 61.9 | 619 |
| 32 | 4 | 57.5 | 36.2 | 70.3 | 703 |
| 34 | 4–1/4 | 64.8 | 40.8 | 77.8 | 778 |
| 36 | 4–1/2 | 72 | 45.8 | 84.2 | 842 |
| 38 | 4–3/4 | 79.8 | 51 | 93.6 | 936 |
| 40 | 5 | 88.1 | 56.5 | 102 | 1020 |
| 42 | 5–1/4 | 95.5 | 62.2 | 111 | 1090 |
| 44 | 5–1/2 | 106 | 68.3 | 118 | 1180 |
| 46 | 5–5/8 | 114.6 | 74.6 | 130 | 1280 |
| 48 | 6 | 125 | 81.3 | 138 | 1380 |
| 50 | 6–1/4 | 135.4 | 88 | 1746 | 1485 |
| 52 | 6–1/2 | 146 | 95.3 | 159 | 1590 |
| 56 | 7 | 169 | 111 | 183 | 1830 |
| 60 | 7–1/2 | 193 | 127 | 205 | 2050 |
| 64 | 8 | 220 | 144 | 230 | 2300 |
| 68 | 8–1/2 | 248 | 163 | 256 | 2560 |
| 72 | 9 | 278 | 182 | 285 | 2850 |
| 76 | 9–3/8 | 309 | 204 | 315 | 3214 |
| 80 | 10 | 343 | 225 | 355 | 3480 |
| 88 | 11 | 417 | 272 | 429 | 4210 |
| 96 | 12 | 497 | 324 | 510 | 5000 |
