Eec L5e Approved Three Wheel Pickup Truck

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Model No.	FL600ZH-A
Max. speed	≤65km/h
Economic speed	60km/h
Fuel consumption	≤5L/100Km
Grade ability	≤20 percent
Max. turning diameter	≤7.5m
Wheel track	1250mm
Wheel base	2170mm
Min. clearance	180 mm
Rate passenger number	2 persons(Incl. driver)
Wheel / Air pressure	145R12/300Kpa
Max. Turning angle of front wheel	28°/28°(L/R)
Dimensions(L x W x H)	3320 mm×1500 mm×1530 mm
Engine model	SQRB2G06
Engine type	Vertical, two-cylinders, four stroke
Bore / stroke	72x72
Rated power / rotating speed	24Kw/5500r/min
Max. torque / rotating speed	48Nm/3000-3500r/min
Min. idling speed	1000±50r/min
Displacement	586ml
Compression ratio	9.8:1
Fuel grade	>RQ-93
Start	Electric
Lubrication method	Force-feed and splashing
Spark	F6RTC
Oil type	API SF SAE 10W/30 or 5W/30
Steering gear	Left / gear rack
Clutch	Dry
Gear box	Manual, four gears, constant mesh gear
Fuel tank capacity	21L
Battery	12V/47Ah
Catalytic converter	ZS004
ECU	0 109 072 103
Carbon tank	200cc
Oxygen sensor	Zirconium oxide
Loading capacity	350kg
Dimensions of rear box	1050 mm x1280 mm x310 mm
