Economic Pressure Transmitter

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port Xi'an
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shaanxi, China	Brand Name	LG
Model Number	LG-MPT400 Melt Pressure and Temperature Transducer	Usage	Pressure Sensor
Theory	Capacitance Sensor	Output	Switching Transducer

Product Description

Specifications

It can be used in measuring pressure of the fluid of mechanical or equipment, pharmaceutical machinery and food machinery.

l Feature

Based on strain gauges technology, melt pressure transducers/transmitters are developed and made 100% from stainless steel in mass production. Our melt pressure transducers/transmitters are suit to measuring and controlling the pressure of some high temperature melts-such as chemical fiber, plastic, rubber and petrifaction-or other over proof liquids. Our company draws on the advanced technology from aboard and manufactures with imported materials and key apparatus, provides our products with stable work, credible capability, high accuracy, large outputted signal, good dynamic capability, small over proof zero temperature-excursion and other merits.

For application in food industry, melt pressure transducers/transmitters are manufactured without mercury.

LG-MPT400 are extended with a flexible stem extension, which provides a further thermal isolation to the electronic circuitry, with a built-In thermocouple or thermal resistor. LG-MPT400 series allow simultaneous pressure and temperature measurement at a single point The output of melt pressure transducers is of either mili-volt or amplified signal, such as 0~10Vdc or 4~20mA.. The output of melt pressure transducers is of either mili-volt or amplified signal, such as 0~10Vdc or 4~20mA.

l Technology Data

Measuring range	bar	0/10,0/20,0/35,0/50,0/70,0/100,0/200,0/350,0/500,0/700,0/1000,0/1400,0/2000
Combined error	%FS	0.25,0.5,1.0
Signal output@FS	mV/V	2.0,2.5,3.0,3.33
Amplified signal output		0/20mA,4/20mA,0/5Vdc,1/5Vdc,0/10Vdc,1/11Vdc
Supply voltage	Vdc	10(12max.) for MPT of mV/V output signal
Supply voltage	Vdc	24(12-36 acceptable) for MPT of amplified output signal
Repeatability	%FS	0.2
Overload pressure	%FS	150
Input resistance	Ω	350±10%
Output resistance	Ω	350±10%
Insulation resistance	Ω	≥500@100Vdc
Max.temp.@wetted parts	°C	400
Zero adjustment	%FS	±10
Span adjustment	%FS	±6
Temperature effect on ZERO	%FS/10°C	0.5
Temperature effect on SPAN	%FS/10°C	0.5
Temperature measurement		J type(Fe CuNi) thermocouple (standard) others on requests
Thermocouple connection		2 pin(male) plug in
Long period stability	%FS/year	<0.15
Compensated temp. range	°C	0~80
Process connection		1/2”20UNF-2A (standard), M14X1.5, M18X1.5
Electrical connection		6-pin connector (standard) , 8-pin connector, 6-wire shield PVC cable
Max. mounting torque	N.m	40
Net weight	kg	~1
