Product Details
| Standard | AISI, ASTM, BS, DIN, GB, JIS | Dimensions | 20*20*3mm-200*200*24mm | |
| Grade | Q195-Q420 Series | Brand Name | Erf | |
| Model Number | Q235/Q345/SS400/S235/S275 | Type | Other, equal and unequal, angel bar | |
| Application | Construction, building,steel fabrication |
Product Description
JIS Standard Equal Angles
Standard Sectional | Weight | Standard Sectional Dimension (mm) | Weight (kg/m) |
20*20*3 | 0.885 | 80*80*6 | 7.32 |
25*25*3 | 1.12 | 80*80*7 | 8.48 |
30*30*3 | 1.36 | 80*80*8 | 9.55 |
30*30*4 | 1.78 | 90*90*6 | 8.25 |
30*30*5 | 2.16 | 90*90*7 | 9.59 |
38*38*3 | 1.72 | 90*90*8 | 10.90 |
38*38*4 | 2.26 | 90*90*9 | 12.20 |
40*40*3 | 1.83 | 90*90*10 | 13.30 |
40*40*4 | 2.41 | 100*100*6 | 9.22 |
40*40*5 | 2.95 | 100*100*7 | 10.70 |
50*50*3 | 2.33 | 100*100*8 | 12.10 |
50*50*4 | 3.06 | 100*100*10 | 14.90 |
50*50*5 | 3.77 | 120*120*8 | 14.70 |
50*50*6 | 4.43 | 120*120*10 | 18.20 |
60*60*5 | 4.55 | 120*120*12 | 21.50 |
60*60*6 | 5.41 | 130*130*9 | 17.90 |
65*65*5 | 5.00 | 130*130*10 | 19.70 |
65*65*6 | 5.91 | 130*130*12 | 23.40 |
65*65*8 | 7.66 | 150*150*10 | 22.90 |
70*70*5 | 5.37 | 150*150*12 | 27.30 |
70*70*6 | 6.38 | 150*150*15 | 33.60 |
70*70*7 | 7.35 | 200*200*15 | 45.30 |
75*75*5 | 5.76 | 200*200*20 | 59.70 |
75*75*6 | 6.85 | 200*200*24 | 71.10 |
75*75*7 | 7.94 | 250*250*25 | 93.70 |
75*75*8 | 8.92 | 250*250*28 | 104.00 |
75*75*9 | 9.96 | 250*250*35 | 128.00 |
JIS Standard Unequal Angles
Standard Sectional Dimension(mm) | Thickness (mm) | Weight (mm) | Standard Sectional Dimension (mm) | Thickness (mm) | Weight (kg/m) |
75*50 | 5 | 4.81 | 150*75 | 10 | 17.0 |
75*50 | 6 | 5.67 | 150*75 | 12 | 20.1 |
100*75 | 7 | 9.32 | 150*75 | 15 | 24.8 |
100*75 | 8 | 10.6 | 150*90 | 9 | 16.4 |
100*75 | 10 | 13.0 | 150*90 | 10 | 18.2 |
100*75 | 12 | 15.4 | 150*90 | 12 | 21.6 |
125*75 | 7 | 10.7 | 150*90 | 15 | 26.6 |
125*75 | 8 | 12.2 | 150*100 | 9 | 17.1 |
125*75 | 10 | 15.0 | 150*100 | 12 | 22.4 |
125*75 | 12 | 17.8 | 150*100 | 15 | 27.7 |
150*75 | 7 | 12.1 | 200*100 | 10 | 23.0 |
150*75 | 9 | 15.3 | 200*100 | 12 | 27.3 |
EN Standard Angles
ASTM Standard Angles
