Outdoor Backhaul 5GHz 3Watts OFDM-TDMA Long Distance up to 80km LOS Near-LOS Solution PTP PTMP Solution

TRTH-2350 Outdoor backhaul 5GHz 3Watts OFDM-TDMA Long distance up to 80km LOS Near-LOS Solution PTP PTMP solution 5/10/20/40 MHz Fractional bandwidth

TRTH2350-34 is a 5GHz 3Watts (with 5GHz OFDM balanced-Amp technology) high capacity OFDM-TDMA outdoor radio for Ultra - long distance (Max Distance > 80Km) PTP/PTMP backhaul solution. 5/10/20/40 MHz adjustable channel bandwidth provides the flexibility of deployment channel plan or high capacity backhaul, and variable capacities for different applications --- the highest truly accumulated throughput(uplink +downlink) is up to 50Mbps. It utilizes TDD (TDMA) technology which allowing the balanced uplink / downlink tunnels on a single channel. This radio is primarily designed to provide standard Ethernet interface in a wireless link between distant sites. TRTH2350-34 series has powerful security mechanism - Except the proprietary protocol, it also supports WEP-128 bits and AES-256 bits encryption. All these functions make the network much more secure and reliable.

Time-Division Multiple Access (TDMA)
5GHz 3 Watts Long Distance Backhaul
5GHz OFDM Balanced-Amp Tech
IP-68 Water & Dust Resistant
IEC61000-4-5 Surge Protection
Outstanding MTBF
Max Distance > 80KM

Near LOS coverage has many different situation and depends on the environment....

APPLICATIONS
High capacity backhaul in long distances LOS and Near LOS
5/10/20/40MHz adjustable channel bandwidth
Cost effective alternative to wired network environment
Redundant link between buildings
Dedicated ISP connections for high-reliability subscribers
Enterprises or Institutions LAN and PBX extension

> Product Highlights <
5GHz OFDM Balanced-Amp Technology
TRTH2350-34 has best performance with up to 3Watts output power based on 5GHz OFDM balanced-Amp technology, and that makes TRTH2350-34 to be the most cost effective 5GHz Ultra-long distance outdoor backhaul solution.

Time-Division Multiple Access(TDMA) technique
TDMA tech can avoid the packets collision and send the packets more efficient and stable to improve the capacity and quality of data transmission in long distance (Max distance > 80Km) or NLOS (Near/ Non-Line of sight) situation.

Effective spectrum utility / variable capacities
TRTH2350-34 has 4 channel bandwidths (5/10/20/40 MHz) for optional, which is adjustable via software. This function provides flexibilities of channel plan and variable capacities for different applications.

Low EIRP for long distance and high capacity transmission
TRTH2350-34 improves the throughput performance up to 50~70% in long distance transmission, that means the system has the same performance with lower EIRP (smaller antenna) compare to other standard wifi products.

Proprietary Security
TRTH2350-34 uses proprietary protocol, so it can’t connect to other standard wifi products. It also provides WEP-128 bits and AES-256 bits to build the highest security mechanism to prevent the malicious attacking from the internet.

Antenna Alignment
The site survey function provides the RSSI (signal strength) info to indicate the status of antenna alignment.

Specification : RADIO
Frequency Range 5150-5875MHz
Output Power / Rx Sensitivity
64QAM (54Mbps) 31(±1.5) dBm / -72 dBm
16QAM (36Mbps) 33(±1.5) dBm / -78 dBm
BPSK (18Mbps) 34(±1.5) dBm / -84 dBm
QPSK (6Mbps) 34(±1.5) dBm / -90 dBm
Modulation OFDM-TDMA
Duplex  TDD
Channel Bandwidth 5 / 10 / 20 / 40 MHz
Frequency Stability  ±2 ppm
Range Max Distance 80Km

INTERFACES
RF N-Jack
Ethernet IEEE 802.3(10 Base-T) / IEEE 802.3u(100 Base-Tx)
RSSI (Receive Signal Strength Indication)
CPE Mode Site Survey
Antenna Alignment RSSI

MANAGEABILITY
Management and setup Web-based configuration
Network Architecture PTP / PTMP
Operating System Windows 98 / 2000 / NT / XP
SNMP agents MIB ll
Protocol TCP/IP, IPX/SPX, NetBEUI
DHCP support DHCP Client

SECURITY
Data Encryption WEP-128 bits / AES-256 bits
Advanced Security Group Name / Proprietary protocol

ENVIRONMENT
Operating Temperature -30~70°C
Storage Temperature -30~70°C
Humidity 95% non-condensing
POWER SUPPLY & CONSUMPTION
AC 100-264V, 50-60Hz, DC 48V
Power Consumption : 38 Watts
PHYSICAL
Dimension 259 (L) * 250 (W) *75 (H) ; mm
Weight 2.3Kg
ADVANCE
Base Station Scanning RSSI
Watch dog

Antennas Ordering Information:
TRANT5023-P 5.1~5.9GHz 23dBi V:7degrees / H:7 degrees directional panel antenna
TRANT5029-D 5.1~5.9GHz 29dBi V:6degrees / H:6 degrees directional dish antenna
TRANT5032-D 5.1~5.9GHz 32dBi V:4degrees / H:4 degrees directional dish antenna

1 Year Warranty – Made in R.O.C Taiwan

Model is specially designed for Telecom carriers and Internet Providers and they can contact us for a projects or bulk orders discounts.
