high quality quartz tube shortwave infrared heating lamp for IR dryer
- shanghai
- T/T Credit Card
You May Like
-
clear quartz twin tubes infrared lamps for PECVD
-
quartz tubular infrared lamps for Roth&Rau PECVD
-
quartz halogen infrared heating lamps for screen printer conveyor dryer
-
quartz tubular infrared heating lamps for conveyor dryer
-
quartz halogen shortwave infrared emitter for PECVD
-
white plated shortwave IR lamps for solar screen printer dryer
Product Details
| Place of Origin | Anhui, China | Brand Name | Quickly | |
| Color | Other, transparent, Yellow, white coated | Specification | Other | |
| Material | Other, quartz, Quartz, high-calss imported quartz sand and heating filament | Certification | Other, CE, CE, CE approved by EMC |
Product Description
Photovoltaic Solar Application
Product | Short wave IR heat lamp | Medium wave IR heat amp | |
Wave length | 0.75-1.0μm | 2.4-2.7μm | |
Heating response time | 1 second | 1-4min | |
Voltage | 110v/230v/380v/400v,customized available | ||
Max. Length for twin tube | 6000mm | ||
Max. filament temp | 2200°C | 900°C | |
Watt density | 35-200w/cm | 10-30w/cm | |
Working expectation | 5000hours | 20000hours | |
Dia. of twin tube | 23×11mm / 33×15mm | ||
Wall thickness of tube | 0.8mm,1.0mm,1.2mm,1.5mm,1.8mm | ||
Dia. of single tube | Φ10mm, Φ11mm, Φ12mm, 15mm,18mm, 20mm | ||
Max. length for single tube | 1600mm(Φ12mm) | 2000mm(Φ15mm) | |
Main material | filament | tungsten filament | Ni80Cr20 heating wire |
| quartz glass | can resist high temperature, sudden hot and cold | |
Inner structure of quartz tube | Quartz envelope profile , vacuum processing with protective halogen gas inflation, which provide a safe working environment | Quartz envelope profile , Non-vacuum | |
Surface of quartz tube | 1. White reflector/Gold reflector: High heat radiation rate 2. Transparent tube: Normal style 3. Ruby tube for shortwave | ||
Market in
1.Delivery and Package
2.Payment Terms
3.Reply inquiry within 24hours
4.Customize size are welcome,OEM welcome. Sample order are welcome.
5.Every lamp will be tested by our QC department before shipping. Any damage
before delivery will be replaced right away. Damage caused by delivery
and no man-made reason within guarantee will also send the replacement heaters for you.
