Galvanized Steel Frame Greenhouse Kit Vegetable Greenhouse Plastic Greenhouse

* Type: stand alone

* Span width: 9.14/10.67m

* Section: 2m

* Sidewall height: 1.22/1.83m

* Peak height : 4.27/4.88/5.48m

* Covering: 0.15mm 3 layer coextruded - 4 year CLEAR poly film sheet, locked by steel or aluminium spring lock base and spring wire

* Ground stake: 57*57*2.0mm hot dipped galvanized square tubes ground stakes.

* Bow: 50*50*1.6mm hot dipped galvanized square tubes bows

* Gable wall pillar: 4 gable pillars of 50*50*1.6mm hot dipped galvanized square tubes for each end wall

* Roof purlin: 3-5 runs of Φ32x1.5mm hot dipped galvanized roof purlin

* Gable purlin: 50*50*1.6mm hot dipped galvanized square tubes purlin

* Side wall purlin: 2 runs of “hat”shaped galvanized purlin for each sidewall

* Cross bar: Φ32x1.5mm hot dipped galvanized cross bar placed under each bow to strengthen structure

"W" style truss (optional): Φ32x1.5mm hot dipped galvanized "W" -truss system, placed under each bow or every other bow to hang basket and supporting equipment.

* Windbrace: Φ32x1.5mm hot dipped galvanized sidewall windbrace every 25 meters.

* Door: 2m*2m sliding door.

* Sidewall roll up ventilation(optional): manual or electric roll-up vents

* Roof ventilation(optional): roll-up vents or motorized vents

* Suitable for all climate conditions and adaptable to any type of landscape

* The unique square tubes offer maximum strength and greater resistance against snow, ice and wind

* Excellent for natural ventilation by side-wall openings covered by insect nets and roll-up curtains, manually or electrically operated

* Gothic Pitch Reduces Condensation Drip

* The Std. 9m and 10m. wide models, with approximately 8′and 10′ truss height are ideal for hanging basket applications.

* Hot dip galvanized steel pipes for better rust and corrosion protection

* Pre-punched hot dip galvanized framing enable ease of installation.

Detailed information on Greenhouses by YOUR request.
