Linetype Water Leak Sensor WL-03
- 20000 Piece / Pieces per Month
- T/T L/C D/P D/A Credit Card
You May Like
-
CE Approved Wired Water Leak leakage Sensor Water flood soak detector alarm
-
King Pigeon Digital Temperature and Humidity detector HT-01
-
King Pigeon Digital Temperature Sensor DT-01
-
DT-01 Digital Temperature Sensor with remote controller
-
Digital Temperature and Humidity detector, Temperature Sensor,TEMPERATURE DETECTOR
-
Digital Temperature and Humidity detector TH-01
Product Details
| Place of Origin | Guangdong, China | Brand Name | King Pigeon | |
| Model Number | WL-03 | Usage | Other, Water |
Linetype Water Leak Sensor WL-03
Standard box
Product Description
Linetype Water Leak Sensor
Water sensor
Water detector
Alarm water sensor
Alarm water detector
Name: Linetype Water Leak Sensor
Model: WL-03
The Linetype Water Leak Sensor is special for waterproof applications, e. G.: Bedroom, library, museum, warehouse, wareroom, storehouse, depot, depository, depositary, generator room, machine room, engine room, etc. When the water permeates into room, and connects to any point of the linetype detector, the detector will trigger and output one dry contact singal to the alarm system (S3523, S3525, S3526). The alarm system will alert the users immediately.
Functions and Features:
1. Low working voltage, it's safe to any person;
2. Apply to important applications;
3. Large-scale protect, the linetype can up to 50meters;
4. New patent design for house and industry;
5. Range Adjutable: The scale of detection can be divided into four range, through the switching knobs;
6. Safe and reliable: Automatically detect fault lines-off;
Technical Specifications:
Working Voltage: 12-60VDC(12VDC, 24VDC, 48VDC, 60VDC all are ok);
Range Adjustable:
Grade 1: 0 -250KΩ ;
Grade 2: 0 -600KΩ ;
Grade 3: 0 -5MΩ ;
Grade 4: 0 -50MΩ ; (This one is High sensitive Grade, very little water permeates will trigger. )
Output: Dry contact, Normal close and Normal Open are adjustable;
Length of the detect wire: 2m, 10m, 15m, 20m, 30m, 10m is the standard length;
Width and Height of the detect wire: 12mm X 5.5mm;
Weight of the detect wire: 1Kg/m;
Short-circuit resistant value<50 Ω , load voltage <60 V, load current <30 mA;
Static current: <45mA;
Triggercurrent: <65mA;
Working environment: -10 ~ 55° C, 10~98%RH;
Size: 95x37x 30 mm;
Weight: 85g.
